Rockwell Automation Trusted T823 Series User Manual

5. Power Port Trusted Power System
24 Issue 11 Rockwell Automation Publication PD-T823X
5.3. Mechanical
5.3.1. Pin-out CON 1, CON 2
CON 1 on the Power Port connects to the Power Shelf. The pin-out details are shown in
Table 2.
CON 2 is used to connect to other Power Shelves to current share or to connect to a Power
Controller.
Pin Number Signal Name Description
1
2
3
4 ON SYNC Not Used
5 SDA I2C Serial data bus
6 SCL I2C Clock
7 24v Supply from Power port
8
9
10
11
12
13
14
15
16 INT BUS Not Used
17
18
19 SRTN Signal return and V
aux
return
