EXR-5
7
EXPLODED VIEW - BOTTOM
A
A
1
1
2
No.
Part No. Description
1
2
K2418125
K2358105
LOUDSPEAKER MM130 4OHM RIF.2313
PRESSURE RUBBER
3
K2018129 BOTTOM CABINET WITH BOX EXR-5
A
J2289186
(SCREW)
SCREW 3,5x16 TCPR TFR H.8 BRUN
3
