14
Apr.2004
01674701 ECJ1VF1E104Z 0.1UF/16VK CERAMIC CAPACITOR C25,C30,C27,C28,C29,C26,C31,C32,C37,C35
,C24,C14,C33,C36,C1,C9,C10,C11,C16,C13,
C22,C15,C38,C17,C18,C19,C20,C21,C12,C49
,C39,C34,C48,C47,C45,C44,C43,C42,C41,C4
0 on Exp Base board ,
C100,C102,C67,C65,C63,C901,C902,C101,C7
,C4,C1,C62,C9,C14,C22,C23,C31,C32,C59,C
37,C39,C43,C47,C49,C53,C56,C3,C36 on
Jack board,
C385,C387,C350,C372,C276,C353,C297,C25
2,C257,C259,C261,C267,C270,C272,C275,C2
80,C279,C348,C6,C299,C307,C333,C334,C33
6,C338,C340,C343,C344,C346,C422,C449,C4
27,C420,C429,C430,C431,C432,C433,C434,C
435,C438,C439,C442,C388,C444,C461,C122,
C248,C472,C465,C443,C462,C425,C460,C45
5,C454,C453,C452,C451,C450,C463,C407,C3
90,C391,C392,C393,C394,C396,C399,C400,C
401,C402,C403,C404,C428,C406,C415,C423,
C421,C419,C418,C405,C416,C424,C414,C41
3,C412,C411,C410,C409,C408,C417,C98,C63
,C131,C65,C66,C68,C69,C70,C73,C74,C77,C
93,C119,C97,C57,C100,C101,C124,C103,C24
7,C120,C121,C123,C125,C127,C128,C129,C1
30,C96,C34,C49,C48,C47,C45,C43,C42,C41,
C40,C39,C38,C37,C64,C35,C56,C33,C30,C23
,C21,C20,C19,C18,C50,C51,C52,C53,C54,C5
5,C36,C202,C17,C16,C15,C14,C191,C192,C1
96,C199,C190,C201,C231,C230,C132,C233,C
102,C236,C237,C238,C241,C245,C246,C200,
C141,C134,C186,C137,C135,C136,C133,C14
0,C142,C143,C144,C173,C183,C181,C178,C1
38,C175,C167,C171,C170,C169 on Main
board ,C85,C80,C81,C84,C86,C87,C89,C82
on Phones board
,C9,C38,C37,C34,C20,C8,C6,C5,C4,C3 on
Sub board
32
+10
+10
+1
+40
+19
4
01900823 RA2-16V100M-T2 CHEMICAL CAPACITOR C40,C38,C44,C18,C70,C28,C48,C50,C69,C6,
C54 on Jack board,
C74,C77 on Phones board
11
+2
01900834 RA2-16V101M-T2 CHEMICAL CAPACITOR C66,C64,C68 on Jack board ,
C76,C72,C71,C73 on Phones board
3
+4
02014923 RA2-35V470MT2 CHEMICAL CAPACITOR C17,C19,C26,C27,C34,C11 on Jack board 6
# 03560578 RA2-6V331MC-T2 CHEMICAL CAPACITOR C61 on Jack board 1
01674301 ECJ1VC1H680J CERAMIC CAPACITOR C75,C78,C79,C83 on Phones board 4
01454889 RA2-16V470MT2 470UF/16V CHEMICAL CAPACITOR C88,C90 on Phones board 2
01674167 ECUV1H100DCV CERAMIC CAPACITOR C35 on Sub board 1
01674712 ECJ1VF1A105Z CERAMIC CAPACITOR C290,C75 on Main board,
C19,C17,C15,C16,C18 on Sub board
5
+2
02345101 RV2-16V100M-R CHEMICAL CAPACITOR C6,C46,C23,C7,C5,C4,C3,C2,C8 on Exp Base
board,
C10,C33 on Sub board
2
+9
03343045 EEE0JA101SP CHEMICAL CAPACITOR C358,C375,C398,C397,C395,C464,C360 on
Main board
1
+7
01674190 ECUV1H150JCV CERAMIC CAPACITOR C72,C263,C264,C440,C441,C165,C164,C27,
C26,C71 on Main board
10
02129534 ECJ1VB1H102K CERAMIC CAPACITOR C386 on Main board 1
02566945 ECJ1VB1C473K 1608 0.047UF CERAMIC CHIP CAPACITOR C283,C318 on Main board 2
03346089 ECHU1C682JX5 POLYEST. CAPACITOR C316,C303,C295,C289 on Main board 4
01899223 ECHU1H102JX5 POLYEST. CAPACITOR C277,C285 on Main board 2
02126434 ECHU1H821JX5 POLYEST. CAPACITOR C291,C286,C300,C310 on Main board 4
03454912 EEE1HA2R2SR CHEMICAL CAPACITOR C292 on Main board 1
03458790 EEE1CS100SR CHEMICAL CAPACITOR C149,C150,C145,C94,C31,C166,C339,C180,
C188,C239,C266,C168,C313,C271,C335,C35
4,C349,C347,C345,C337,C315,C309,C308,C3
02,C298,C296,C294,C288,C282,C281,C278,C
273,C324 on Main board
33
03454789 EEE1CA220WR CHEMICAL CAPACITOR C284,C274 on Main board 2
03454790 EEE1CA221P CHEMICAL CAPACITOR C253,C258 on Main board 2
03454812 EEE1CA470SP CHEMICAL CAPACITOR C363,C365 on Main board 2
03564345 EEE1AA102P CHEMICAL CAPACITOR C445,C457 on Main board 2
02345145 RV2-16V101M-R CHEMICAL CAPACITOR C437 on Main board 1
02783412 6SVP150 OS-CON CHEMICAL CAPACITOR C244,C254 on Main board 2
01896589 SK4-0J106MZ4-RA TANTALUM CAPACITOR C456,C448,C426,C384,C126,C118,C104,C95,
C59,C46,C44,C29,C13,C22 on Main board
14
CAPACITOR
INDUCTOR, COIL, FILTER
01565578 N1608Z601T01 FERRITE-BEAD L6,L5,L4,L3,L1,L9,L2,L10,L11,L12,L13,L14,
L15,L16,L7,L8 on Jack board,
L17,L18,L34,L19,L20,L5,L36,L21,L37,L16,L3
3,L32,L35,L30,L38,L22,L23,L24,L25,L26,L27,
L28,L29,L31 on Main board ,L21,L19 on
Phones board
16
+2
+24
03125167 SLF12565T-470M2R4 CHOKE COIL L1 on Main board 1
01909645 EXCML16A270U FERRITE-BEAD L4,L3 on Main boards 2
