Roland Fantom XR Service Notes

2
Apr.2004
SPECIFICATIONS
Fantom-XR:
128 Voices Synthesizer/Sampling Module
(Conforms to General MIDI 2 System)
Sound Generator Section
Maximum Polyphony
128 voices (shared with the sampling section)
Parts
16 parts
Wave Memory
128 M bytes (16-bit linear equivalent)
Waveforms
1,480
Preset Memory
Patches: 1,024 + 256 (GM2)
Rhythm Sets: 40 + 9 (GM2)
Performances: 64
User Memory
Patches: 256
Rhythm Sets: 32
Performances: 64
Card Memory (PC card)
Patches: 256
Rhythm Sets: 32
Performances: 64
Effects
Multi-Effects: 3 systems, 78 types
Chorus: 3 types
Reverb: 5 types
Input Effect: 6 types
Mastering Effect: 3 bands Compressor
Sampling Section
Data Format
16-bit linear (File Type: .WAV/.AIFF)
Sampling Frequency
44.1 kHz (fixed)
Maximum Sampling Time
When sampling memory isn’t expanded (16 MB)
mono: 180 sec. approx., stereo: 90 sec. approx.
When sampling memory is expanded with DIMM (528 MB)
mono: 104 min. approx., stereo: 52 min. approx.
Number of Samples
User memory: 2,000 (maximum total approximately 16 MB)
Card memory: 7,000 (PC card)
Others
Arpeggio
Preset: 128
User: 128
Rhythm Pattern
Preset: 256 (32 groups)
User: 256 (32 groups)
Chord Memory
Preset: 64
User: 64
Display
Graphic 160 x 48 dots backlit LCD
Connectors
Headphones Jack
A (MIX) Output Jacks (L/MONO, R): 1/4 inch phone type
B Output Jacks (L, R): 1/4 inch phone type
Input Jacks (L/MONO/MIC, R): 1/4 inch phone type
MIDI Connectors (IN, OUT, THRU)
USB Connector (supports file transfer (mass storage class) and MIDI)
Digital Audio Interface (COAXIAL INPUT/OUTPUT)
AC Inlet
Expansion Slots
• Expansion of waveforms and patchs for the internal sound generator
SRX expansion boards: 6 slots
• Expansion of sampling memory
DIMM: 1 slot (supports 128 MB, 256 MB, 512 MB (3.3 V))
External Storage Device
PC Card: 1 slot (supports SmartMedia and CompactFlash using a PC card
adapter)
Power Supply
AC 117 V, AC 230 V, AC 240 V (50/60 Hz)
AC 220 V (60 Hz)
Power Consumption
13 W
Dimensions
481 (W) x 335 (D) x 44 (H) mm
18-15/16 (W) x 13-3/16 (D) x 1-3/4 (H) inches
Weight
3.75 kg / 8 lbs 5 oz
Accessories
Owner’s Manual ENGLISH:(#72567634)
JAPANESE(#72566356)
Sample Data (Audio) CD:(#********)
CD-ROM (Editor, USB MIDI driver):(#03674712)
PC Card Protector(#03566612) (and 2 screws):(#40012456)
Power Cord 120V:(#00894378)
230V:(#00894389)
240VA:(#23495124)
240VE:(#00907001)

Roland Fantom XR Specifications

General

Polyphony	128 voices
Multitimbral	16 parts
Wave Memory	128 MB (16-bit linear equivalent)
Display	240 x 64 dots backlit LCD
MIDI	In, Out, Thru
Storage	SmartMedia card slot
Expansion Slots	4 x SRX
Effects	Chorus: 3 types; Reverb: 5 types
Sampling	Yes
USB	Yes (MIDI)
Audio Outputs	4 (L/Mono, R, 3, 4)
Audio Inputs	2 (L/Mono, R)
