22
Apr.2004
14: Noise
fig.ltest-noise_100
1. This check for noise during silence.
Set the INPUT and OUTPUT volumes to the maximum position, and verify
that no noise is heard from the following output jacks.
• Headphones
• OUTPUT A
• OUTPUT B
2. Press to proceed to the next test item.
15: Factory Reset
fig.ltest-reset_100
• Press to execute Factory Reset.
fig.ltest-now-reset_100
• When Factory Reset is completed, you will automatically proceed to the
next test item.
16: (Completed)
fig.ltest-completed_100
• All tests have been completed. Turn off the power.
RESTORING THE FACTORY
SETTINGS
If there is important data you’ve created that’s stored in the Fantom-XR’s
internal memory, all such data is discarded when a Factory Reset is performed
(the data of the internal user memory will be lost). If you want to keep the
existing data, save it on a memory card or save it on via USB to your computer
.
1. Select “Factory Reset” in the Utility Menu screen, and press [ENTER].
A message will ask you for confirmation.
2. Press [ENTER] to execute the Factory Reset.
* To cancel, press [EXIT].
3. When the display indicates “Power Off,” turn the power off, then on
again.
SYSTEM SOFTWARE UPDATE
PROCEDURE
The Fantom-XR uses flash memory for its program ROM, and can be updated
using either of the following two methods.
1. Updating from a PC card using the Fantom-
XR’s PC card slot
2. Updating from a computer via a USB cable
connected to the Fantom-XR
Required items
1. UPDATE DATA FOR SERVICE CD-ROM (#17041429)
2. Computer (with USB connector; Windows Me, Windows 2000, or
Windows XP operating system)
3. One PC card (with 32MB or more free space)
4. USB cable
If user memory contains important data, please save the data (see Saving and
Loading User Data) before you perform the update.
1. Updating from a PC card using the
Fantom-XR’s PC card slot
1. Obtain the update file “fanx.bin” and use a PC card reader etc. to place
the file on the card in the following folder hierarchy relative to the root
directory of the card.
/ROLAND/LINE/fanx.bin
2. Insert the card and turn on the power; the update will begin.
fig.up-card
* Never turn off the power while the update is occurring.
3. When the update is completed, the following display will appear.
fig.up-cardend
Turn off the power and remove the card.
2. Updating from a computer via a
USB cable connected to the Fantom-XR
1. Download the update file fanx.bin onto your computer.
Before you continue, you should also save the contents of the Fantom-
XR’s user memory on a memory card or on your computer via USB.
2. Power-on the Fantom-XR without the USB cable connected.
3. Go to the System USB screen, and set USB Mode to “STORAGE.”
4. Press , and then press to select System Write.
5. Power-off the Fantom-XR, then use a USB cable to connect the Fantom-XR
to your PC, and power-on the Fantom-XR.
6. While the System Version Info screen (shown below) is displayed,
consecutively press , , , , and
.
To Next Page
