Roland Gaia SH-01 User Manual

9
Using the GAIA SH-01 with a Computer or
Sound Module . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Recording the SH-01’s Sound or Data on a Computer
(USB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Connecting the SH-01 to Your Computer . . . . . . . . . . 42
Using the SH-01 as a Controller or Sound Module
(MIDI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
MIDI Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
About MIDI Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Advanced Operation . . . . . . . . . . . . . . . . . . . . . 45
Patch Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
D BEAM ASSIGN Parameters . . . . . . . . . . . . . . . . . . . . . . 48
Eect Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
System Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
USB Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Using USB Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Initializing USB Memory . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Saving User Patches to USB Memory . . . . . . . . . . . . . . 56
Restoring Data from USB Memory to
the GAIA SH-01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Saving Your Recorded Phrases to USB Memory . . . . 56
Restoring Phrases from USB Memory to
the GAIA SH-01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Saving All User Data to USB Memory . . . . . . . . . . . . . . 57
Restoring All Data from USB Memory to
the GAIA SH-01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Restoring the Factory Settings . . . . . . . . . . . . 58
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 59
MIDI Implementation Chart . . . . . . . . . . . . . . 61
Main Specications . . . . . . . . . . . . . . . . . . . . . . 62
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Roland Gaia SH-01 Specifications

General

Type	Virtual Analog Synthesizer
Polyphony	64 voices
Keyboard	37 keys (velocity-sensitive)
Arpeggiator	Yes
Synthesis Type	Virtual Analog
Sequencer	No
MIDI	In, Out
Connectivity	MIDI, USB
Oscillators	3
Effects	Reverb, Delay, Flanger, Distortion
Weight	4.2 kg
LFO	1
Filter	High-pass, Low-pass, Band-pass
USB	Yes
Memory	64 Patches
Power Supply	AC adapter (included)
Outputs	Stereo Output (L/MONO, R)
