11
Mar. 2006 HPD-10
Parts List
fig.part1e
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
CASING
# 04129445 ESCUTCHEON D-BEAM CONTROLLER 1
# 04129567 BOTTOM COVER 1
# 04129423 PAD HOOP 1
# 04129556 REAR PANEL 1
# 04129412 TOP CASE 1
# 04129545 TOP PANEL 1
# 04124990 PLAYING PLATE 1
CHASSIS
# ******** LCD HOLDER 1
* The LCD HOLDER is included in the PANEL BOARD ASSY (#73129523). Order the PANEL BOARD ASSY.
# 04129534 STAY HOLDER 1
KNOB, BUTTON
03125589 M R-KNOB MF-ELA BLK/LCG 1
03565789 M R-KNOB LF-ELA BLK 1
12499175 BUTTON JSPUE0011A 1
# 04129589 RUBBER SW 1
SWITCH
01676512 PUSH SWITCH SDKLA10200 SW1 on MAIN 1
JACK, EXT TERMINAL
00569278 6.5MM JACK LGR4609-7100F JK2, 3, 4, 7, 8 on MAIN 5
13449711 AC ADAPTOR JACK HEC0470-01-630 JK1 on MAIN 1
02892878 DIN(MIDI) JACK 2DJ-00600003 JK5, 6 on MAIN 2
DISPLAY UNIT
# ******** LCD LMC-SSC16104DFG 1
* The LCD is included in the PANEL BOARD ASSY (#73129523). Order the PANEL BOARD ASSY.
PWB ASSY
#
73129501 MAIN BOARD ASSY 1
# 73129489 SENSOR BOARD ASSY 1
# 73129523 PANEL BOARD ASSY 1
* The PANEL BOARD ASSY includes the following parts.
******** LCD
******** LCD HOLDER
04129445 ESCUTCHEON
12169368 LED SPACER
TRANSISTOR
00897201 TRANSISTOR 2SA1706S-AN Q3 on MAIN 1
DIODE
01900612 DIODE TPS611(F) IC2 on PANEL 1
03126134 LED(INFRARED) TLN233(F) LED1 on PANEL 1
POTENTIOMETER
02891812 12M/M ROTARY POTENTI-
OMETER
RK12L12C0C08 VR1 on PANEL 1
INDUCTOR, COIL, FILTER
01672889 CHOKE COIL SBC3-221-681 L5 on MAIN 1
12449347 FERRITE-BEAD EXC ELDR35V L4 on MAIN 1
02780389 CHOKE COIL ELC10D470E L6 on MAIN 1
Service Notes(A4)_e 11 ページ ２００６年６月１日 木曜日 午後４時５分
