PATCH SETTINGS
While holding down the MANUAL button, press one of the numeric buttons to select the parameter
BEND RANGE [13] 1-12,13,16 Specifies the pitch bend range in semitones - Default is [2]
OFF is [16]
DELAY LEVEL [14] 1-16 Adjusts the volume of delay (OFF = 1)
DELAY TIME [15] 1-16 Adjusts the delay time
DELAY FEEDBACK [16] 1-16 Adjusts the delay feedback
Main Specifications
MAXIMUM POLYPHONY 4 Voices
POWER SUPPLY Rechargeable Ni-MH Battery (AA, HR6) x 4 Alkaline battery (AA, LR6) x 4,
USB Power
CURRENT DRAW 500 mA (USB Bus Power)
DIMENSIONS 300 (W) x 128 (D) x 45 (H) mm | 11 13/16 (W) x 5 1/16 (D) x 1 3/4 (H) inches
WEIGHT 940 g | 2 lbs 2 oz
ACCESSORIES Owners Manual, leaflet “using the unit safely”, Alkaline battery (AA) x 4
Options
