2
Apr. 2006 JUNO-G/JUNO-G (J)
Cautionary Notes
User data status
User data status after each of the following processes is described below.
Whenever carrying out procedures that involve deleting or erasing user data,
always be sure to back up the user data to some form of external storage
media. Refer to Data Save (User Backup) (p. 15).
* Executing Test Mode during Factory Reset deletes the user data.
Parts List
Due to one or more of the following reasons, parts with parts code ********
cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
Circuit Diagram
In the circuit diagram, ‘NIU’ is an abbreviation for ‘NOT IN USE’.
The circuit board and circuit-board diagram show silkscreened indications, but
no components are mounted.
Specifications
JUNO-G: Synthesizer Keyboard (Conforms to General MIDI 2 System)
Keyboard
61 keys (with velocity)
■
Sound Generator Section
Maximum Polyphony
128 voices (shared with audio track section)
Parts
16 parts
Wave Memory
64 M bytes (16-bit linear equivalent)
Preset Memory
Patches: 768 + 256 (GM2)
Rhythm Sets: 36 + 9 (GM2)
Performances: 64
User Memory
Patches: 256
Rhythm Sets: 32
Performances: 64
Effects
Multi-Effects: 3 systems, 78 types
Chorus: 3 types
Reverb: 5 types
Input Effects: 6 types
Mastering Effects: 3-band compressor
■
Song Recorder Section
Tracks
MIDI tracks: 16
Audio tracks: 4 stereo tracks
Tempo track: 1
Beat track: 1
Song Length
9998 measures
Tempo
5–300
MIDI Track
Resolution: 480 TPQN
Note Capacity: approx. 400,000 notes
Recording Method: Realtime recording, Step recording
Process User Data
Checking Version number Preserved
Factory Reset Deleted
System Update Deleted
Test Mode Preserved
