7
Apr. 2006 JUNO-G/JUNO-G (J)
Exploded View (1) Parts List
No. Parts Code Parts Name Description Q'ty
1 04124267 J R-KNOB SF-ELA BLK/SLV 1
2 01676512 PUSH SWITCH SDKLA10200 1
3 04451556 CORD HOOK MNP 1
4 04128090 D R-KNOB L-ELA MNP 1
5 04124278 S-KNOB SLV 5
6 04124301 PROTECTOR PC CARD 1
7 04124267 J R-KNOB SF-ELA BLK/SLV 6
8 04122867 TOP PANEL 1
9 04124223 SIDE PANEL L 1
10 04128778 DISPLAY COVER 1
11 04010634 LCD 1
12 04124256 LCD HOLDER 2
13 04124234 SIDE PANEL R 1
14 04231889 PANEL-A BOARD ASSY 1
15 04235178 INSULATING SHEET FOR PANEL-A BOARD 1
16 04231890 PANEL-B BOARD ASSY 1
17 04235189 INSULATING SHEET FOR PANEL-B BOARD 1
18 73342067 PANEL-C BOARD ASSY JAPAN equivalent to #04231923 1
19 04235190 INSULATING SHEET FOR PANEL-C BOARD 1
20 03234723 BENDER PB-H0204 1
21 03671278 METAL HOLDER FOR SIDE PANEL 2
22 04124334 PWB HOLDER 5
23 73342078 LCD BOARD ASSY 1
24 00673067 PWB SPACER WLS-04-0 4
25 04344189 KEYBOARD ASSY MSK-2 61KEY (W/O CABLE) 1
25 04344201 CABLE ASSY FOR MSK-2 1
26 04124323 PANEL HOLDER 3
27 73342089 JACK BOARD ASSY JAPAN equivalent to #04231934 1
28 73342090 MAIN BOARD ASSY JAPAN equivalent to #04231867 1
29 03671290 REINFORCE BAR 1
30 04129323 SHIELD SHEET 1
31 04124212 BOTTOM CASE 1
32 04124245 EXPANSION COVER 1
33 12359137 RUBBER FOOT SJ-5012 BLK 4
To Next Page
