PARTS LIST(KC-550)
fig.part1e
PRE-> PRE BOARD(SHEET A), JCK -> JACK BOARD(SHEET A)
PS1-> PS1 BOARD(SHEET B), AMP-> AMP BOARD(SHEET B),
PS-> PS BOARD(SHEET B)
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
CASING
SD000345 VELCRO AC CABLE 8INCHI W/4 INCH 1
SD000349 BADGE HOLDER 1
# SD000220 PUNCHING GRILL 1
# SD000592 LOGO BADGE (ROLAND) 1
# SD000593 LOGO PLATE KC GOLD 1
# SD000626 CABINET ASSY 1
NOTE: “CABINET ASSY” includes the following parts.
# SD000628
2-LEG METAL CORNER BLACK
8
12359104 RUBBER FOOT G-5R 4
22310207 HANDLE (H40)
231-207 W/ESCUCHEON (2 HOLES)
1
# SD000571 PORT TUBE 2’X4.5 BLACK PLASTIC 2
# SD000627 CASTER SOCKET 4
CHASSIS
# SD000702 PRE CHASSIS 1
01786045 SW HOLDER AT-217K 1
12369410RT AC CORD HOLDER 1702B 2
# SD000689 SUB CHASSIS 1
KNOB,BUTTON
# SD000598 KNOB(BLCK) GOLD PLATE 10
2249752100 PUSH BUTTON BLACK #521 1
SWITCH
13159178 SLIDE SWITCH SSSU122500 SSW1 on JCK 1
01782623 SWITCH SPUP128100 PSW1 on PRE 1
13119218 ROTARY SWITCH SRBM132400 RSW1 on PRE 1
01786012 SEESAW SWITCH JW-M11RKK 1
JACK,EXT TERMINAL
00122123 XLR CONNECTER YKF52-5003 JK12,JK13 on JCK 2
03234590 RCA(PIN) JACK YKC21-3503 JK14 on PS1 1
13449275 6.5MM JACK YKB21-5074 JK2-3 on JCK 2
13449146 6.5MM JACK YKB21-5012 (W/SW) JK4-11 on JCK,JK15-17 on PS1 11
13449145 6.5MM JACK YKB21-5010 JK18 on PRE 1
# SD000622 TERMINAL PT1870502 TER1-2 on PS1,TER3-5 on PS 5
01902645 XLR CONNECTOR NC3FAH2 W/LOCK PIN JK1 on JCK 1
# SD000632 TERMINAL JH-8M3 TER7-8 on JCK, TER6,9 on PS1 4
SPEAKER, BUZZER
# SD000634 SPK-KC-550-TW SPEAKER HORN TWEETER 1
# SD000633 SPK-KC-550-FW SPEAKER (15INCH WOOFER) 1
PWB ASSY
# SD000208 SHEET A BOARD ASSY 1
NOTE: “SHEET A BOARD ASSY” includes the following parts. 1
******** SHEET A BOARD ASSY (PRE BOARD 1/2) 1
******** SHEET A BOARD ASSY (JACK BOARD 2/2) 1
# SD000209 SHEET B BOARD ASSY 1
NOTE: “SHEET B BOARD ASSY(100V/117V)” includes the following parts.
******** SHEET B BOARD ASSY (PS1 BOARD 1/3) 1
******** SHEET B BOARD ASSY (AMP BOARD 2/3) 1
******** SHEET B BOARD ASSY (PS BOARD 3/3) 1
03670512 5ST 4A/250V FUSE on FUSE 1 1
NOTE: Replacement SHEET B BOARD ASSY is for 100V/117V version exclusive use.
To Next Page
