(CABINET)
[KC-550 PARTS]
[KC-350 PARTS]
No PART CODE PART NAME DESCRIPTION Q’TY
1 SD000626 CABINET ASSY 1
NOTE:CABINET ASSY includes the following parts.
2 SD000628 2-LEG METAL CORNER BLACK 8
3 12359104 RUBBER FOOT G-5R 4
4 SD000571 PORT TUBE 2’X4.5 BLACK PLASTIC 2
5 22310207 HANDLE (H40) 231-207 W/ESCUCHEON (2 HOLES) 1
6 SD000627 CASTER SOCKET 4
7 SD000634 SPEAKER HORN TWEETER SPK-KC-550-TW 1
NOTE:SPEAKER HORN TWEETER includes the following parts.
14 ******** TWEETER GASKET 1
8 SD000633 SPEAKER (15INCH WOOFER) SPK-KC-550-FW 1
9 SD000220 PUNCHING GRILL 1
10 SD000592 LOGO BADGE (ROLAND) 1
11 SD000593 LOGO PLATE KC GOLD 1
12 SD000349 BADGE HOLDER 1
13 SD000345 VELCRO AC CABLE 8INCHI W/4 INCH 1
15 SD000680 CASTER(W/O SOCKET) 3020-11-SR 4
m 40011689 SPEED NUT M3 F-TYPE 2
No PART CODE PART NAME DESCRIPTION Q’TY
1 SD000630 CABINET ASSY 1
NOTE:SPEAKER HORN TWEETER includes the following parts.
2 SD000628 2-LEG METAL CORNER BLACK 8
3 12359104 RUBBER FOOT G-5R 4
4 SD000571 PORT TUBE 2’X4.5 BLACK PLASTIC 2
5 22310207 HANDLE (H40) 231-207 W/ESCUCHEON (2 HOLES) 1
7 SD000692 TWEETER DRIVER SPK-KC-350-TW 1
NOTE:SPEAKER HORN TWEETER includes the following parts.
14 ******** TWEETER GASKET 1
8 SD000691 SPEAKER (12INCH WOOFER) SPK-KC-350-WF 1
9 SD000220 PUNCHING GRILL 1
10 SD000592 LOGO BADGE (ROLAND) 1
11 SD000593 LOGO PLATE KC GOLD 1
12 SD000349 BADGE HOLDER 1
13 SD000345 VELCRO AC CABLE 8INCHI W/4 INCH 1
m 40011689 SPEED NUT M3 F-TYPE 2
