CAUTIONARY NOTES
PARTS LIST
Due to one or more of the following reasons, parts with parts code ********
cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CIRCUIT BOARD
NIU meant that "NOT IN USE " there don't set any contents in the Circuit
Diagram.
There has silk-screen only in the Circuit Board.
SPECIFICATIONS
Rated Power Output
[KC-550] 180 W
[KC-350] 120 W
Nominal Input Level (1 kHz)
Channel1 (MIC/LINE): -50 -- -20 dBu
Channel2--4 (LINE): -20 dBu
STEREO LINK INPUT: 0 dBu
AUX IN : -10 dBu
Nominal Output Level (1 kHz)
LINE OUT(XLR type, Phone type): +4 dBu
STEREO LINK OUTPUT: 0 dBu
SUBWOOFER OUT: +4 dBu
LINE OUT Jacks (XLR type) are KC-550 only.
0 dBu = 0.775 Vrms
Speakers
[KC-550] 38 cm (15 inches) x 1, Tweeter x 1
[KC-350] 30 cm (12 inches) x 1, Tweeter x 1
Controls
CHANNEL CONTROL
CH1
VOLUME Knob
CH2
VOLUME Knob
CH3
VOLUME Knob
CH4
VOLUME Knob
OUTPUT SELECT Switch
PHONES VOLUME Knob
MASTER CONTROL
EQUALIZER
LOW Knob
MIDDLE Knob
HIGH Knob
SHAPE Switch
VOLUME Knob
POWER Switch
GND LIFT Switch (KC-550 only)
Indicator
POWER
Connectors
CH1 INPUT Jack (XLR type)
CH1--4 INPUT L(MONO) Jacks (1/4” phone type)
CH1--4 INPUT R Jacks (1/4” phone type)
LINE OUT L(MONO) Jacks (XLR type, 1/4” phone type)
LINE OUT R Jacks (XLR type, 1/4” phone type)
AUX IN Jacks (RCA phono type)
SUBWOOFER OUT Jack (1/4” phone type)
STEREO LINK OUT Jack (1/4” phone type)
STEREO LINK IN Jack (1/4” phone type)
PHONES Jack (Stereo 1/4” phone type)
LINE OUT Jacks (XLR type) are KC-550 only.
Power Supply
AC 117 V, AC 230 V, AC 240 V:50/60Hz
AC 220V:60Hz
Power Consumption
[KC-550] 135 W
[KC-350] 100 W
Dimensions
[KC-550]
590 (W) x 445 (D) x 590 (H) mm
23-1/4 (W) x 17-9/16 (D) x 23-1/4 (H) inches (including casters)
590 (W) x 445 (D) x 536 (H) mm
23-1/4 (W) x 17-9/16 (D) x 21-1/8 (H) inches (excluding casters)
[KC-350]
490 (W) x 385 (D) x 470 (H) mm
19-5/16 (W) x 15-3/16 (D) x 18-9/16 (H) inches
Weight
[KC-550]
29.0 kg
63 lbs 15 oz
[KC-350]
22.0 kg
48 lbs 9 oz
Accessories
[KC-550]
Owner’s Manual ENGLISH (#SD000216)
JAPANESE (#SD000215)
Casters (#SD000680) X 4
[KC-350]
Owner’s Manual ENGLISH (#SD000216)
JAPANESE (#SD000215)
To Next Page
