Roland SRA-200E - Main Specifications

Main Specifications
• Rated Power Output
100 W x 2 (stereo, 8 ohms load, 1 kHz, 0.1 % or less
THD)
150 W x 2 (stereo, 4 ohms load, 1 kHz, 0.1 % or less
THD)
300 W (BTL, 8 ohms load, 1 kHz, 0.5 % or less THD)
• Frequency Response
20 Hz to 50 kHz (+0/- 1 dB, 1 W/8 ohms)
• Input Impedance
Balanced Input: 10 k ohms
Unbalanced Input: 10 k ohms
• Input Sensitivity
-10 dBm/+4 dBm
• Non-Clip Maximum Input
+24 dBm
• Recommended Load Impedance
4 ohms or greater (stereo)
8 ohms or greater (BTL)
• Power Band Width
20 Hz to 20 kHz (stereo, 8 ohms load, 50 W, 0.2 % or
less THD)
20 Hz to 20 kHz (BTL, 8 ohms load, 150 W, 0.2 % or less
THD)
• Total Harmonic Distortion
0.05 % or less (stereo, 8 ohms load, 1 kHz, 50 W)
0.05 % or less (stereo, 4 ohms load, 1 kHz, 75 W)
0.07 % or less (BTL, 8 ohms load, 1 kHz, 150 W)
• S/N Ratio
100 dB or greater (input terminate with 150 ohms,
input sensitivity +4 dBm, IHF-A weighted)
• Damping Factor
125 or greater (8 ohms load, 1 kHz)
• Channel Separation
65 dB or greater (8 ohms load, 1 kHz, 50 W, DIN audio
weighted)
• Slew Rate
11 V/micro sec or greater (stereo, 8 ohms load)
• Controls
Attenuators x 2 (A, B)
Power Switch
MODE Switch (STEREO/BTL)
INPUT LEVEL Switch (+4 dBm/-10 dBm)
• Indicators
Power Indicator
Clip Indicators (A, B)
Level Indicators (A, B)
Protection Indicator
• Connectors
Balanced Input Jacks (1/4 inch TRS phone type) x 2 (A,
B)
Balanced Input Connectors (XLR-3-31 type) x 2 (A, B)
Balanced Input Terminals x 2 (A, B)
Speaker Terminals (Binding Posts) x 2 (A, B)
• Power Supply
AC 117/230/240 V (50/60 Hz)
• Power Consumption
130 W (AC 117/230/240 V)
• Dimensions
482 (W) x 364 (D) x 48.6 (H) mm
19 (W) x 14-3/8 (D) x 1-15/16 (H) inches
(EIA-1U rack mount type)
• Weight
5.0 kg/11 lbs 1 oz
• Accessories
Owner's Manual
Rubber Feet x 4
0 dBm = 0.775 V rms
* In the interest of product improvement, the specifications and/or appearance
of this unit are subject to change without prior notice.
