Roland TD-1DMK User Manual

11
Appendix
Troubleshooting
Problem Items to check Action
Problems with sound
No sound
Is the TD-1 correctly connected to the external devices?
Check the connections.
Could the cable be connected to an output jack (instead of the input) of
the connected amplied speaker?
Are the cables correctly connected to the unit’s OUTPUT/PHONES jack?
Could an audio cable be broken? Try using a dierent cable.
Check whether you hear sound through headphones.
If you hear sound in the headphones, there is a problem with the
connection cables or with the connected amplied speaker.
Could the TD-1 volume be lowered?
Adjust the volume to an appropriate level.
Could the volume of the connected amplied speaker be lowered?
Could the volume be lowered on the device connected to the MIX IN jack?
Is the connection cable correctly connected to the TRIGGER INPUT
connector?
Check the connections.
A specic pad does not sound
Are the cables correctly connected to each pad and pedal?
Could the pad’s “Sensitivity” be lowered? Adjust the pad’s “Sensitivity.”
Is the pad’s “Type” set correctly? Set the pad’s “Type.”
No sound when you press the
kick pedal
Is the cable labeled KIK connected to the kick pad?
Check the connections.
No sound when you press the
hi-hat pedal
Is the cable labeled HHC connected to the hi-hat pedal?
The sound of another pad is
also
heard when you strike
the pad.
If multiple pads are attached to the same stand, the vibration of a strike
can be transmitted to another pad, causing it to sound inadvertently.
Reattach the pad at a dierent location.
Two or more notes are sounded
when you strike once
Is the pad fastened to the stand? Fasten the pad rmly to the stand.
Sounds do not play reliably Is the pad’s mesh head tensioned evenly?
Adjust the mesh head tension. Slightly higher tension is good for
proper triggering.
Problems with USB
Can’t connect with a computer Is the USB cable connected correctly? Make sure that the USB cable is correctly connected.
Problems with MIDI
No sound from external MIDI
device
Is the MIDI channel set correctly? Set the MIDI channel of external MIDI device to 10.
Has the note number been set properly? Check the pad’s “Note#.”
Main Specications
Roland TD-1: Drum Sound Module
Drum Kits 15
Songs 15
Display 7 segments, 3 characters (LED)
Interface USB MIDI (Transmitting only)
Power Supply AC adaptor
Current Draw 150 mA
Dimensions
106 (W) x 43 (D) x 181 (H) mm
4-3/16 (W) x 1-3/4 (D) x 7-1/8 (H) inches
Weight
(excluding AC adaptor)
236 g
9 oz
Accessories
Owner’s Manual
Leaet “USING THE UNIT SAFELY”
AC adaptor
Power cord
* This document explains the specications of the product at the time that the
document was issued. For the latest information, refer to the Roland website.

Roland TD-1DMK Specifications

General

Type	Drum system
Kick pedal	Yes
Number of pieces	1 pc(s)
Display type	LED
USB connector type	USB Type-B
USB ports quantity	1
Power source type	AC

Weight and Dimensions

Depth	1100 mm
Height	1200 mm
Weight	17800 g
