FEATURES
Fig. 1
THROTTLE
TRIGGER
STARTER GRIP
ENGINE HOUSING
FRONT HANDLE
IGNITION
SWITCH
TRI-ARC BLADE
BLADE GUARD
SHAFT
STRAP
HANGER
SHOULDER
STRAP
GEAR HEAD
COUPLER
KNOB
GRASS DEFLECTOR
CUTTING
LINE
LINE CUT-
OFF BLADE
THROTTLE
INTERLOCK
UNPACKING
INSTRUCTIONS
■■
■■
■ Carefully remove the product from the carton.
■■
■■
■ Inspect the product to make sure no breakage or
damage occurred during carriage.
■■
■■
■ Do not discard the packing material until you have
inspected and operated the product.
PACKING LIST FOR OWNER’S KIT
■■
■■
■ Grass deflector
■■
■■
■ Blade guard
■■
■■
■ Tri-Arc blade
■■
■■
■ Shoulder strap
■■
■■
■ Silencer guard, torque wrench and screws
■■
■■
■ Front Handle
■■
■■
■ Holding pin
■■
■■
■ Spanners - 13 mm (1/2 in) and 16 mm (5/8 in)
■■
■■
■ Fixings
■■
■■
■ Operator’s manual
HANDLE BARRIER
BAR
