Ryobi RCS2340B User Manual

9
WHATS IN THE BOX
RCS2340B
Chainsaw x1
Guide bar cover x1
Operators manual x1
SYMBOLS ON THE PRODUCT
Safety alert
To reduce the risk of injury, user
must read and understand operators
manual before using this product.
Wear eye, ear and head protection.
Wear non-slip safety footwear when
using the product.
Wear non-slip, heavy duty gloves.
Remove plug from the mains
immediately before maintenance or if
cable is damaged or cut
Beware of chain saw kickback and
avoid contact with bar tip.
Do not expose to rain or damp
condition.
Hold and operate the saw properly
with both hands.
Do not operate the saw using only
one hand.
Class II tool, double insulation
Regulatory Compliance Mark (RCM).
requirements.
Waste electrical products should not
be disposed of with household waste.
Check with your local authority or
retailer for recycling advice.
The guaranteed sound pressure level
is 96 dB.
The guaranteed sound power level is
107 dB
Bar and chain lubricant
Chain brake
Rotate to lock or unlock the guide bar
Lock
Unlock
Moving direction of the chain.
(Marked under the sprocket cover)
SYMBOLS IN THIS MANUAL
Connect to power outlet.
Disconnect from power outlet.
Note
Warning
Wear eye and face protection.
Wear upper body protection.
Wear leg protection.
Stop the product.
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.

Ryobi RCS2340B Specifications

General

Power source	AC
Idle speed	- RPM
Chain speed	16 m/s
Blade length	400 mm
Product color	Black, Green
Ergonomic handle	Yes
Oil tank capacity	0.15 L

Weight and Dimensions

Weight	4800 g
