13
SPECIFICATIONS
Product Specifications
Net weight 21.2 kg
Chuck size 13 mm (1/2")
Speed 5 (510-2430 min
-1
)
Motor 230-240 V, 50Hz
Horsepower 390 W
Table Size 195 mm x 165 mm
(7-5/8" x 6-1/2")
Table tilt 45º right or left
Spindle travel 50 mm (2")
Throat 127 mm (5")
Laser Class 2
Measured sound pressure
level
L
pA
= 57.5 dB(A)
Uncertainty K 3 dB(A)
Measured sound power
level
L
WA
= 70.5 dB(A)
Uncertainty K 3 dB(A)
RECOMMENDED ACCESSORIES
WARNING
Use only accessories recommend for this drill press.
Follow instructions that accompany accessories. Use of
improper accessories may cause hazards.
■ Drill bits
■ Hold-down clamps
■ Drill press vices
WARNING
Use only accessories designed for this drill press to
avoid injury from thrown broken parts or workpieces.
Do not use any accessory unless you have completely
read the instruction or operator’s manual for that
accessory.
exposed wires and cut or worn insulation.
WARNING
Keep the extension cord clear of the working area.
Position the cord so that it will not get caught on lumber,
tools or other obstructions while you are working with
a power tool. Failure to do so can result in serious
personal injury.
WARNING
Check extension cords before each use. If damaged
replace immediately. Never use tool with a damaged
cord since touching the damaged area could cause
electrical shock resulting in serious injury.
ELECTRICAL CONNECTION
This tool is powered by a precision built electric motor.
It should be connected to a power supply that is 230-
240 V, 50 Hz, AC only (normal household current). Do
not operate this tool on direct current (DC). A substantial
voltage drop will cause a loss of power and the motor will
overheat. If the tool does not operate when plugged into
an outlet, double check the power supply.
SPEED AND WIRING
The no-load speed of this tool is approximately 2,850 rpm.
This speed is not constant and decreases under a load
or with lower voltage. For voltage, the wiring in a shop
is as important as the motor’s horsepower rating. A line
intended only for lights cannot properly carry a power tool
motor. Wire that is heavy enough for a short distance will
be too light for a greater distance. A line that can support
one power tool may not be able to support two or three
tools.
GROUNDING INSTRUCTIONS
In the event of a malfunction or breakdown, grounding
provides a path of least resistance for electric current to
reduce the risk of electric shock. This tool is equipped with
an electric cord having an equipment-grounding conductor
and a grounding plug. The plug must be plugged into a
matching outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Do not modify the plug provided. If it will not t the outlet,
have the proper outlet installed by a qualied electrician.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. The
conductor with insulation having an outer surface that
is green with or without yellow stripes is the equipment-
grounding conductor. If repair or replacement of the
electric cord or plug is necessary, do not connect the
equipment-grounding conductor to a live terminal.
Repair or replace a damaged or worn cord immediately.
