Ryobi RDP102L User Manual

2
DESCRIPTION
1. Head assembly
2. Table
3. Base
4. Rack
5. Column assembly
6. Rack ring
7. Feed handles
8. Worm gear
9. Table lock handle
10. Table crank handle
11. Hex bolts
12. Chuck
13. Chuck key
14. 4 mm hex key
15. 3 mm hex key
16. Slotted Screwdriver
17. Adjustable wrench
18. 12 mm wrench
19. Hammer or rubber mallet
20. Combination square
21. Block of wood
22. Motor
23. Laser head
24. Quill return coil / spring
25. Table bracket
26. Pulley cover
27. ON/OFF switch
28. Laser switch
29. Upper safe guard
30. Mounting holes
31. Head locking screw
32. Belt tension lock knob
33. Chuck key holder
34. Spindle pulley
35. Motor pulley
36. Table support
37. Table crank handle hole
38. Column support
39. Set screw
40. Head
41. Head locking set screw
42. Threaded holes
43. Hub assembly
44. Spindle
45. Bolt (not included)
46. Lock washer (not included)
47. Rubber washer (not included)
48. Flat washer (not included)
49. Jam nut (not included)
50. Hex nut (not included)
51. Worksurface
52. Bevel scale
53. Table bevel locking bolt
54. Nut
55. Lock nut
56. Screw
57. Lower front notch
58. Spring cap
59. Outer jam nut
60. Inner nut
61. Notch
62. Boss
63. Chuck jaws
64. Drill bit
65. Depth
66. Depth scale pointer
67. Depth scale
68. Upper nut
69. Lower nut
70. Depth stop lug
71. Workpiece

Ryobi RDP102L Specifications

General

Product type	Drill stand
Product color	Black, Grey, Steel
Lever	Yes
Chuck type	Key
Control type	Buttons, Lever
Drill table tilting	0 - 45 °
