4
ENGLISH
DESCRIPTION OF FIGURES
Figure 4
30. Washer
31. Wing nut
32. Bolt
Figure 5
33. Slot
34. Tab
35. Wing screw
Figure 6
36. Hanger bracket
Figure 7
37. Red LED
38. Orange LED
Figure 8
39. Battery port
40. Battery
Figure 10
41. Direction of rotation
Figure 11
42. Dangerous cutting area
43. Best cutting area
44. Direction of rotation
Figure 12
45. Trimmer line cut-off blade
Figure 15a
46. Start position
Figure 15b
47. Run position
Figure 16
48. Drive shaft
49. Cutting head
50. Spool retainer
Figure 17
51. Pull lines from holes to remove
52. Slot
53. Hole
54. Slot
55. Hole
Figure 18
56. Idle speed screw
Figure 19
57. Latch
Figure 20
58. Latch
59. Filter screen
60. Air filter cover
Figure 21
61. Idle speed screw
62. Air filter cover
ASSEMBLY
UNPACKING
This product requires assembly.
n Carefully remove the tool and any accessories from the box.
Make sure that all items listed in the packing list are included.
n Inspect the tool carefully to make sure no breakage or damage
occurred during shipping.
n Do not discard the packing material until you have carefully
inspected and satisfactorily operated the tool.
n If any parts are damaged or missing do not operate this
product until the parts are replaced.
PACKING LIST
Trimmer Assembly
Pro Cut II
TM
Line Head
Spool Retainer
Shoulder Strap
12 Volt Battery
Charger
Front Handle
Wing Screw
Wing Nut
Bolt
Washer
Grass Deflector
Bottle of 2-Stroke Lubricant
Hanger Cap
Operator’s Manual
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark plug
wire from the spark plug and remove battery pack when
assembling parts.
INSTALLING THE POWER HEAD SHAFT TO THE ATTACHMENT
See Figure 2.
WARNING:
Never install, remove, or adjust any attachment while
power head is running. Failure to stop the engine can
cause serious personal injury.
The attachment connects to the power head shaft by means of a
coupler device.
n Loosen the Wing Screw on the coupler of the power head shaft
and remove the end cap from the attachment.
n Push in the button located on the attachment shaft. Align the
button with the guide recess on the power head coupler and slide
the two shafts together. Rotate the attachment shaft until the button
locks into the positioning hole.
NOTE: If the button does not release completely in the positioning
hole, the shafts are not locked into place. Slightly rotate from side
to side until the button is locked into place.
n Tighten the Wing Screw securely.
