5
ENGLISH
ASSEMBLY
WARNING:
Be certain the Wing Screw is fully tightened before
operating equipment; check it periodically for tightness
during use to avoid serious personal injury.
REMOVING THE ATTACHMENT FROM THE POWER HEAD
For removing or changing the attachment:
n Loosen the Wing Screw.
n Push in the button and twist the shafts to remove and separate
ends.
ATTACHING THE HANGER CAP
See Figure 3.
There are two ways to hang your attachment for storage.
n To use the hanger cap, push in the button and place the hanger
cap over end of the lower end attachment shaft. Slightly rotate
the cap from side to side until the button locks into place.
n The secondary hole in the attachment shaft can be used for
hanging purposes as well.
ATTACHING THE FRONT HANDLE
See Figure 4.
n Remove wing nut, washer, and bolt from the front handle.
n Install the front handle onto the top side of the drive shaft housing.
NOTE: The open side of the handle should face the operator.
n Place the bolt through the front handle.
NOTE: The hex bolt head fits inside the hex recess moulded into
one side of the handle.
n Reinstall the washer and wing nut.
n Tighten wing nut securely.
WARNING:
The line cutting blade on the grass deflector is sharp.
Avoid contact with the blade. Failure to avoid contact can
result in serious personal injury.
ATTACHING THE GRASS DEFLECTOR
See Figure 5.
n Remove the wing screw from the grass deflector.
n Insert the tab on the mounting bracket in the slot on the grass
deflector.
n Align the screw hole in the mounting bracket with the screw hole
in the grass deflector.
n Insert the wing screw through the mounting bracket and into
the grass deflector.
n Tighten the screw securely.
Attaching the Shoulder Strap
See Figure 6.
Follow these steps to attach the shoulder strap.
n Connect the latch on the strap to the hanger bracket.
n Adjust the strap to a comfortable position.
FEATURES
PRODUCT SPECIFICATIONS
Engine Displacement..............................................................30 cm³
Cutting Path Diameter................................................17 in / 432mm.
String Diameter..............................................................2.4/2.7 mm.
Battery Voltage.......................................................................12 Volt
Mass (without fuel, cutting attachment and guard)................6.37 kg
Mass (without fuel with string head)..........................…............6.7kg
Volume (fuel tank)..................................................................415cm³
Maximum engine perform
(in accordance with ISO8893)................................................0.70kw
Maximum rotational frequency of the spindle...................12000/min
Engine speed (rotational frequency) at recommended max.
spindle rotational frequency..............................................12000/min
Engine speed (rotational frequency) at idling............2800-3500/min
Fuel consumption (in accordance with ISO8893)
at max. engine performance..............................0.48kg/h or 0.66 L/h
Specific fuel consumption (in accordance with ISO8893)
at max. engine performance.....................640 g/kw.h or 0.87 L/kw.h
Vibration levels for idling and racing (for idling and with wide open
throttle for grass trimmers) when measured in accordance
with 4.2Vibration level idling for Front handle and
Rear handle.....................................................3.5 m/s² and 3.3 m/s²
Vibration level racing for Front handle and
Rear handle.................................................14.5 m/s² and 10.4 m/s²
Sound pressure level
(in accordance with EN2791)........................................100.7 dB (A)
Sound power level
(in accordance with ISO10884)........................................109 dB (A)
KNOW YOUR LINE TRIMMER
See Figure 1.
The safe use of this product requires an understanding of the
information on the tool and in this operator’s manual as well as a
knowledge of the project you are attempting. Before use of this
product, familiarise yourself with all operating features and safety
rules.
CHARGER
The charger has a key-hole hanging feature for convenient, space-
saving storage. Screws should be installed so that the centre
distance is 11.5cm
ELECTRIC START
The line trimmer has an electric start which can be used in place
of the pull start.
PRO CUT II
TM
LINE HEAD
The line trimmer is provided with an additional cutting head.
GRASS DEFLECTOR
The line trimmer includes a grass deflector that helps protect you
from flying debris.
SHOULDER STRAP
The line trimmer includes a shoulder strap that helps support the
product.
TOP-MOUNTED MOTOR
The top-mounted motor improves balance and is located away
from the dust and debris of the cutting area.
