- 23 -
Fig. 4.5 Slave device wiring terminals
Notice
·Please use the battery cable in original package.
·Do not share 1 lithium battery slave device on 2 AS1.
4.5 Communication Interface Description
Fig. 4.6 RS232 pins
Pin number
Name
2
RS-232 TX
3
RS-232 RX
4
GND
Table 4.2 RS232 pins description
