Green lamp flicker from
bottom to top
Green lamp flicker from
top to bottom
Red lamp flicker:1 s/time
Green lamp and red lamp
flicker in alternative
Procedures are being upgrade
Residual battery capacity percentage
(SOC)
Total remained battery capacity of the system
Table 5.1 Human-computer interface description
5.2 System Commissioning
After finishing connecting wiring, please install the communication modules.
Use eSolar O&M software to realize initialization of the device. (Terminal users
please check relevant info by eSolar Air)
Notice: before starting slave device, open the battery switches and BMS
switches first.
5.3 Start Up the Inverter
The inverter can be turn ON by the following steps:
1. Turn ON the DC switch on the right side of the inverter;
2. Press the battery switch on the right side of the inverter, a blue light will be
shown on the button area;
3. Wait for about half minute, and observe the LCD and LED indicators on
the front of the inverter.
