SAJ PDS23 Plus User Manual

PDS23 Plus Series
- 11 -
2.4 PDS23Plus Solar Pump Controller Model Description
2.4.1 Model Description
PDS23Plus2.2K
①②③④
Segment
Description
Options
①
PDS series
②
Series ID
2: Series of 2nd generation.
3: Apply to three-phase induction motor
③
Plus
Enhancement type
④
Motor Power Rating
2.2K: 2.2kW; K: kW
Note 1:Rated input voltage 540VDC , recommended Voltage(MPP) 500VDC-700VDC ;
2:Supporting alternating current input, with voltage rating of 380VAC three phase
connected to terminal R, S and T.
2.4.2General parameters of PDS23 Solar Pump Controller
General Parameters
Protection
Surge Protection
Integrated
Overvoltage Protection
Integrated
Undervoltage Protection
Integrated
Locked pump Protection
Integrated
Open circuit Protection
Integrated
Short circuit Protection
Integrated
Overheated Protection
Integrated
Dry Run Protection
Integrated
Communication
MODBUS Communication
RS-485 Isolated
Others
Ambient Temperature Range
-20°C～60°C;>45°C, Derating as Required
Cooling Method
Fan Cooling
Ambient Humidity
≤ 95%RH
Level of Protection
IP65
Certificates
IEC/EN 61800-5-1,IEC/EN 61800-2:2004,IEC/EN61800-3:2004,CE

SAJ PDS23 Plus Specifications

General

Brand	SAJ
Model	PDS23 Plus
Category	Controller
Language	English
