SAJ PDS23 Plus User Manual

PDS23 Plus Series
- 21 -
4.1.2Indicator Light Instruction
RUN: (Always on)running instruction;(Flicker)sleep instruction
STOP: stop or standby instruction
ALM1: controller fault alarm
ALM2: water shortage or full of water alarm
4.2 Keypad Operation Process
4.2.1 Parameter Setting
Three levels of menu are as following：
• Function code group (first-class)
• Function code (second-class)
• Setting parameter of function code (third-class)
In order to set up the electric automatic start function FD.07=11 as an example, the
modified parameter flow chart is as follows:
Figure11Schematic Diagram of Function Parameters
Display
Reading:
Button:
Stand By Status
0.00
f0
First Class
fd
fd.07
0.00
fd
fd.10
11
10
Run Status
Third Class
Value N ow
N ew Value
(Frequency/Hz)
(Frequency/Hz)
Display
Reading:
Button:
PRG M
▲
▲
EN T
EN T
EN T
First Class
First Class
Second Class
PRG M
PRG M
Second Class
Third Class
