SYNCHRONISING THE BOILER CONTROL
(a) RT500 programmable room thermostat RF Sync mode
- Press and hold "SELECT" to enter ID transmission;
ID code is set by 5 position jumper switches;
- TX sends ID code for 10 minutes.
- during 10 minutes synchronisation, LCD shows "Sy" on
temperature digits and the timer will count down.
- during 10 minutes synchronisation, pressing any key can interrupt ID
code transmission and LCD will return to normal mode, i.e.
temperature and clock.
(b) Boiler Control RF Sync mode
- Press and hold "SYNC" button on the boiler control for a few seconds to
enter ID learning mode, LED flashes.
- Until ID is captured and memorized into EEPROM (within max 12
minutes), LED stops flashing and stays ON (relay close) or OFF (relay
open) if ID is never captured, LED will keep flashing to alert user to
re-sync, until 12 minutes timeout.
To pair the RT500 to the Boiler Module simply press and hold the sync
button on the Boiler module for 3 seconds, at the same time press and
hold Select on the RT500 for 3 seconds, after 3 seconds at the same time
release both the sync button on the boiler module and the select button on
the RT500.
If the Boiler Control successfully receives a signal from the RT500 during the
pairing operation, the Boiler Control will store the new RF address code into
its internal memory. The LED will flash twice if the code is stored correctly,
or 4 times if this was unsuccessful. The Boiler Control will then exit pairing
mode and the LED will go out.
RT500BC INSTRUCTION MANUAL
10
Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 10
