Salus RT510 User Manual

7
2.3 Wall mounting
RT510 front Backplate
(two screws at the bottom)
Wiring conguration
1
2
3
COM
NO
NC
Fit the front housing.
Press lightly.
Fix the backplate
to the wall.
Align the front housing
at the top edge
.
Content used for thermostat mounting:
How to mount the thermostat to the wall:
1 2 3
