6 Electrical Parts List
6-1
0 LS21DPWASQ/EDC 215TW,WSA1/S21A2-LDP,21,LCD-MO,NETHERLAN
0.1 M0002 BN90-00823S ASSY COVER REAR;LS21DPWAB/XAA 1 S.N.A
..2 M0013 BN96-03390A ASSY COVER P-REAR;LS21DP,HIPS HB BK24 1 S.A
...3 M0006 BN63-02470A COVER-REAR;LS215TW,HIPS,T2.3,HB,BK24 1 S.N.A
0.1 M0001 BN90-00898A ASSY COVER FRONT;LS21DPWASQ/EDC 1 S.N.A
..2 T0003 BN96-03194B ASSY COVER P-FRONT;LS21DP,ABS HB GR70,SV 1 S.A
...3 BN61-02120A BRACKET-SPEAKER;LS07BTT,SECC,T2.0,W70,W2 2 S.N.A
...3 M0112 BN63-02471B COVER-FRONT;LS21DP(S/M215TW),ABS,T2.0,HB 1 S.N.A
...3 T0022 BN64-00479B KNOB CONTROL;LS21DP,ABS,T1.0,HB,GR70 (CL 1 S.N.A
...3 M0145 BN96-03270A ASSY BOARD P-FUNCTION;LS21DPWAB,SJ06-01- 1 S.A
...3 C/F BN96-03296A ASSY BOARD P-AUDIO;LS21DPWAB,SJ05-01-006 1 S.N.A
...3 T0175 BN96-01660B ASSY SPEAKER P;8ohm,Doppler,1 W,30mm 1 S.A
...3 T0175 BN96-01660C ASSY SPEAKER P;8ohm,Doppler,1 W,350mm 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.N.A
0.1 M0216 BN90-00899A ASSY STAND;LS21DPWASQ/EDC 1 S.N.A
..2 M0003 BN96-03196B ASSY STAND P;LS21DP,ABS HB,GR70+BK24 1 S.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.N.A
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 S.N.A
...3 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
...3 M0081 6003-001238 SCREW-TAPTITE;FH,+,S,M4,L8,ZPC(BLK),SWRC 2 S.N.A
...3 HC+CW 6009-001370 SCREW-SPECIAL;PWH,+,-,M4,L8,ZPC(YEL),SWR 1 S.N.A
...3 BN61-01396A HOLDER-SWIVEL RING;MJ17MS,ACETAL,NTR 1 S.N.A
...3 CIS4 BN61-01438A HOLDER-STAND;MATISSE HAS-STAND,SWRCH18A 1 S.N.A
...3 BN61-02398A BRACKET-STAND LIFT;LS215TW,SECC,T2.0 1 S.N.A
...3 BN61-02399A GUIDE-STAND LIFT;LS215TW,P.O.M,WHT 2 S.N.A
...3 BN61-02400A BRACKET-STAND FRAME;LS215TW,SECC,T2.0 1 S.N.A
...3 BN61-02401A GUIDE-STAND BODY;LS215TW,P.O.M,WHT 1 S.N.A
...3 BN61-02402A BRACKET-STAND BOTTOM;LS215TW,SECC,T2.0 1 S.N.A
...3 BN63-02476A COVER-STAND FRONT;LS215TW,HIPS,T2.5,HB,B 1 S.N.A
...3 BN63-02477A COVER-STAND REAR;LS215TW,HIPS,T2.5,HB,BK 1 S.N.A
...3 BN63-02481A COVER-STAND TOP;LS215TW,HIPS,T2.5,HB,BK2 1 S.N.A
...3 BN63-02482A COVER-STAND VESA;LS215TW,HIPS,T2.5,HB,BK 1 S.N.A
...3 BN63-02483A COVER-STAND TILT;LS215TW,HIPS,T2.5,HB,BK 1 S.N.A
...3 BN63-02484A COVER-STAND LIFT FRONT;LS215TW,HIPS,T2.5 1 S.N.A
...3 BN63-02485A COVER-STAND LIFT REAR;LS215TW,HIPS,T2.5, 1 S.N.A
...3 T0081 BN73-00085A RUBBER CUSHION;MATISSE,##4.5(IN SIDE),CL 1 S.N.A
...3 T0054 BN96-03193A ASSY HINGE P;LS215TW,ZNDC 1 S.N.A
...3 CCM1 6001-001547 SCREW-MACHINE;BH,+,M4,L10(5),ZPC(BLK),SW 2 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 BN61-02437A SPRING ETC-SPIRAL;LS215TW,SUS,18.5,130,T 2 S.N.A
...3 T0514 BN61-02454A BRACKET-SUPPORT;LS21DPW,SECC,T1.0 1 S.N.A
...3 T0004 BN63-02478B COVER-STAND BASE;LS21DPW,HIPS,T2.5,HB,GR 1 S.N.A
...3 T0003 BN63-02480A COVER-STAND BOTTOM;LS215TW,HIPS,T2.5,HB, 1 S.N.A
...3 T0132 BN73-00077A RUBBER FOOT;MATISSE,BUMPON,##13.5,T2.0,6 4 S.N.A
...3 M0007 BN96-01524A ASSY STAND P-STOPPER;MJ17BS,SUS T1.0,L26 1 S.N.A
0.1 T0852 BN91-00939U ASSY LCD-SPZ;LS21DPW* 1 S.N.A
..2 M0215 BN07-00230A LCD-PANEL;LTM210M2-L02,Dvorak,8BIT,477.6 1 S.A
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LS21DPWASQ/EDC Parts list
Level Loc. No. Code No. Description & Specification EA SA/SNA
To Next Page
