1
To stop the blades moving left and right, set the Swing switch to the
position.
2
Set the Swing switch to the position.
Result:
The inner blades swing automatically left and right.
To stop the blades in a specific position and orient the air flow in the
corresponding direction, simply set the switch to the position when
the blades are in the desired position.
➢
Adjusting the Air Flow Direction Horizontally
Adjusting the Air Flow Direction Vertically
The inner air flow blades on the rigth side of the unit can be adjusted to direct the air
flow to the left, right or straight, thus increasing the efficiency of the air conditioner.
The side by side air direction louvers are controlled by a lever.
They regulate air discharge to the left, right or straight.
The outer air flow blades can be adjusted to control the vertical air
flow direction.
RECOMMENDATION
When...
Cooling
Adjust the blades to face...
Upwards.
AW1010A/AW1210A
AW0700A/AW0700B/AW0800A/AW1000A/AW1200A/AW1800A
Adjust the air flow blades to the desired position, by pushing them
upwards or downwards.
◆
If you orient the air flow blades downwards and the unit operates
in Cool mode for long periods of time, dew may:
-
Form on the surface of the blades
-
Drip from the blades
➢
E-
9
