Samsung Electronics4-2
4-1 Indoor Unit
No Parts Procedure Remark
1 Front Grille
1) Stop the air conditioner operation and
shut off the main power.
2) Open the Front Grille by pulling right and
left sides of the hook.
3) Loosen 1 of the right screw and detach
the Terminal Cover. (Use +Screw Driver.)
4) Detach the thermistor from the Front
Grille.
5) Loosen 3 fixing screws of Front Grille.
(Use +Screw Driver.)
Stop operation of the air conditioner and remove the power cord before repairing the unit.
4-1-1 MH026FNCA/MH035FNCA/MH052FNCA
To Next Page
