Samsung NC10 User Manual

93
Wireless Network
A wireless network allows computers to share resources or an internet connection
without using LAN cables between them.
 This description is applied only to the models equipped with wireless LAN cards or
devices. You can set a wireless network by using Samsung Network Manager as
well. 99
A wireless LAN device is optional when purchasing. Click a symbol, +, from Start
> Control Panel > Performance and Maintenance > System > Hardware Tab >
Device Manager > Network Adapter to check the device type.
Some of the pictures shown in this description may vary depending on the wireless
LAN device.
 Press the Fn + key and enable the wireless LAN features to use wireless LAN.
Once the wireless LAN is enabled, the wirelss LED turns on.
Types of Wireless LAN Connections
The types of wireless LAN connections
are as follows. The following describes
how to use the wireless LAN based on
AP connections.
 AP Connections
You can connect to the Internet or a
computer on the network by connecting
to AP on an AP-enabled network.
What is Access Point (AP)?
AP is a network device that connects
wired LAN to wireless LAN and
corresponds to the wireless hub of a
wired network. Also, AP allows you
to connect more than one computer
where wireless LAN is enabled.
 Small Ofce Network
The small ofce network interconnects
computers where wireless LAN is
enabled wirelessly and is called Peer-
to-Peer (or Ad HOC). This method
enables the conguration of a small
ofce network in one computer.
Then, another computer is connected
to the computer wirelessly for
communications.
For more information on how to
establish connections, see the
information from Start > Help and
Support > Networking and Web.
When you use Ad-Hoc, you have to
change the McAfee Firewall settings.
185

Samsung NC10 Specifications

General

Bus type	FSB
Stepping	C0
Tjunction	90 °C
Processor cache	0.512 MB
Processor cores	1
Processor model	N270
Processor family	Intel Pentium Mobile
Processor series	Intel Atom N200 Series
Processor socket	Socket F (1207)
Processor threads	2
Processor codename	Diamondville
Processing Die size	26 mm²
Processor frequency	1.6 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	533 MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	2.5 W
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	47 M
Memory slots	1x SO-DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	2 GB
HDD speed	5400 RPM
HDD capacity	160 GB
HDD interface	SATA
Card reader integrated	Yes
Compatible memory cards	MMC, SD, SDHC
Display diagonal	10.2 \
Display resolution	1024 x 600 pixels
Native aspect ratio	5:3
Dimensions (WxDxH)	261 x 185.5 x 30.3 mm
Wireless technology	802.11b/g
Maximum graphics card memory	0.128 GB
Audio system	HD Audio
Speaker power	3 W
Front camera resolution (numeric)	1.3 MP
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Bluetooth version	2.0+EDR
Mobile network generation	3G
Bundled software	SAMSUNG Recovery Solution III, SAMSUNG Magic Doctor, SAMSUNG Update Plus, Easy Display Manger, Easy Battery Manager, SAMSUNG Network Manager, Easy SpeedUp Manager, McAfee SecurityCenter, Adobe Acrobat Reader
Operating system installed	Windows XP Home Edition
Product type	Netbook
Product color	White
Cable lock slot type	Kensington
Battery capacity	5200 mAh
Battery life (max)	8.5 h
Number of battery cells	6
AC adapter power	40 W
Processor code	SLB73
Processor ARK ID	36331
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3

Weight and Dimensions

Depth	185.5 mm
Width	261 mm
Height	30.3 mm
Weight	1330 g
