Samsung NX30 User Manual

4-10
Manual
Connecting to an Access Point (AP)
This section describes how to connect to an AP. You can use the network when you
are connected to an AP.
1. Right-click on the Wireless Network Connection ( ) icon on the taskbar,
and select View Available Wireless Networks.
2. Select an AP (E.g. Test) to connect to and click Connect.
When the network key dialog box appears, enter the network key and click
Connect.
Now when Connected in AP is displayed, and you can access the network.
The connection setup is described for a computer running on Windows XP Service
Pack 2. If you are using the Windows 2000 system, refer to P. 4-15 ‘Wireless
Network Setup Using the Wireless LAN Setup Program’. For more detailed infor-
mation such as the network key (encryption key), ask your network administrator.
N
N
o
o
t
t
e
e
Checking the connection status.
Move the mouse pointer over the Wireless
Network Connection ( ) icon on
the taskbar, and the connection status is displayed.
N
N
o
o
t
t
e
e
N
N
o
o
t
t
e
e
When a network key is not
defined for a selected AP,
click on Link to display
the warning message box.
Then click Connect again in
the box.

Samsung NX30 Specifications

General

Megapixel	20.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	21.6 MP
Image sensor size	- \
Maximum image resolution	5472 x 3648 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Image stabilizer location	Lens
Still image resolution(s)	5472 x 3648, 3888 x 2592, 2976 x1984, 1728x 1152, 2736 x 1824, 5472 x 3080, 3712 x 2088, 2944 x 1656, 1920 x 1080, 3648 x 3648, 2640 x 2640, 2000 x 2000, 1024 x 1024, 5472 x 3648, 2688 x 1512, 1920 x 1080
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Samsung NX
Maximum aperture number	5.6
Minimum aperture number	3.5
Focus	TTL
Normal focusing range	11 m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	-
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Video recording	Yes
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 810, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1037000 pixels
Magnification	0.96 x
USB version	2.0
Scene modes	Portrait, Landscape (scenery)
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Manual, Tungsten
Shooting modes	Aperture priority, Auto, Program, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	- s
Power source type	Battery
Battery type	BP1410
Battery voltage	7.6 V
Battery capacity	1410 mAh
Battery life (max)	3 h
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	127 mm
Width	41.7 mm
Height	95.5 mm
Weight	375 g
