Setting up your French Door Refrigerator
7
8
9
ASSEMBLE THE FREEZER DRAWER
1. Pull out the rails fully on each side of the cabinet.
2. Attach the freezer door front onto the open slots on the sides.
3. Tighten 4 hex head bolts completely with a socket
wrench(7/16”).
4. Insert the lower basket ( 6 ) into the rail system.
5. Hook the ends of the tilting pocket ( 7 ) onto the support
guards ( 8 ) and push down until they lock into place.
6. Insert the upper drawer.
6
Remove 2 pieces of tape ( 9 ) attached to the side of the
drawer bin.
Reattach the tape in the same position when moving the
refrigerator to prevent scratching the drawer bin.
