Samsung ST45 User Manual

20
Starting the recording mode
6. Select the [Voice] menu by pressing the Up / Down button and
press the OK button.
7. Select the [Off] menu by pressing the Left / Right button.
8. Press the OK button. You can record a movie without sound.
Ä
See p.44 for further details.
You can record the movie clip without sound.
Steps from 1 -3 are the same as those for
MOVIE mode.
4. Press the Menu button.
5. Press the Up / Down button to select the
[Functions] menu and press the Right
button.
Recording the movie clip without sound
How to use the Movie clip mode ( )
A movie clip can be recorded for as long as the available recording
time (maximum of 20 minutes) of the memory capacity allows.
1. Use the Mode switch to select Movie
Clip mode. (The Movie clip mode icon
and available recording time will display
on the LCD monitor.).
2. Point the camera towards the subject
and compose the image by using the
LCD monitor.
3. Press the Shutter button once and movie clips are recorded for
up to 20 minutes. Movie clips will still be recorded if the shutter
button is released. If you wish to stop recording, press the shut-
ter button again.
Ä
Image size and type are listed below.
- Image size : 800x592, 640x480, 320x240 (Selectable)
- Movie clip fi le type : AVI (MPEG-4)
- Frame Rate : 30 FPS, 20 FPS, 15 FPS (Selectable)
- The frame rate can be selected when the following image size
is selected.
800x592: 20FPS selectable
640x480, 320x240: 30FPS, 15FPS selectable
- If the recording time is takes longer 20 minutes, the recording
is stopped and then saved.

Samsung ST45 Specifications

General

Megapixel	12.2 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	4000 x 3000 pixels
Optical zoom	3 x
Focal length range	6.3 - 18.9 mm
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	500MHz
Dimensions (WxDxH)	96 x 17.7 x 56.9 mm
Minimum storage drive space	250 MB
Minimum system requirements	USB, CD-ROM
Compatible operating systems	Windows 2000 / XP / Vista, Mac OS 10.3
Focal length (35mm film equivalent)	35 - 105 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 - ∞ m
Auto focusing (AF) modes	centre weighted auto focus, multi point auto focus, selective auto focus
Closest focusing distance	0.1 m
Macro focusing range (tele)	0.5 - 0.8 m
Macro focusing range (wide)	0.1 - 0.8 m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Flash modes	auto, fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 2 m
Flash range (wide)	0.4 - 3 m
Flash recharging time	4 s
Internal memory	31 MB
Compatible memory cards	mmc, sd, sdhc
Motion JPEG frame rate	20 fps
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Scene modes	Backlight, Night, Night portrait, Portrait, self-portrait, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
Camera playback	movie, single image, slide show
Self-timer delay	2 s
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	17.7 mm
Width	96 mm
Height	56.9 mm
Weight	105 g
