Samsung ST45 User Manual

69
Setting play interval
Set the Multi Slide Show play interval.
1. Select the [Interval] sub menu by
pressing the UP / DOWN button and
press the RIGHT button.
2. Use the Up / Down buttons to select
the desired interval.
3. Press the OK button to save the
configuration.
Back Set
Images :All
Effect :Off
Interval :1 sec
Music :Off
Start
1 sec
3 sec
5 sec
10 sec

The loading time depends on the image size and quality.

While the Multi Slide Show is playing, only the first frame
of a MOVIE file is displayed.

While the Multi Slide Show is playing, the voice recording file
will not display.

The interval menu functions in the [Off] menu only.
Starting the Multi Slide Show
(

)
Set the Multi Slide Show music.
1. Select the [Music] sub menu by pressing
the UP / DOWN button and press the
RIGHT button.
2. Use the Up / Down buttons to select the
desired Music.
3. Press the OK button to save the
configuration.
Setting Background Music
Back Set
Images :All
Effect :Off
Interval :1 sec
Music :Off
Start
Off
Mist
Muse
Fall
Dawn
Party
Deleting images
1. Press the Up / Down button and select
the [Delete] menu tab. And then press
the Right button.
2. Select a desired sub menu by pressing the
UP / DOWN button and press the OK button.
[Select] : Selection window for an image
to delete is displayed.
- Up/ Down/ Left/ Right : Select an image
- OK button : Select the image for
deletion. (
Ë
mark)
- Delete Button : Press the Delete button to
display the confirmation
message. Select the [Yes]
menu and press the OK
button to delete marked
images.
[All] : Displays confirmation window.
Select the [Yes] menu and press the
OK button to delete all unprotected
images. If there aren’t protected
images, all the images are deleted and a [No Image File]
message will appear.
3. After deletion, the screen will be changed to the play mode screen.
This deletes images stored on the memory.
1. Press the play mode button and press the menu button.
2. Press the Up / Down button and select the [File Options] menu
tab and press the OK button.
1 31 31211 5
Select Delete
Delete All File(s)?
Yes
No
Set
Back Set
Protect
Voice memo :Off
DPOF
Copy To Card
Delete
Select
All
File Options
( )

Samsung ST45 Specifications

General

Megapixel	12.2 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	4000 x 3000 pixels
Optical zoom	3 x
Focal length range	6.3 - 18.9 mm
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	500MHz
Dimensions (WxDxH)	96 x 17.7 x 56.9 mm
Minimum storage drive space	250 MB
Minimum system requirements	USB, CD-ROM
Compatible operating systems	Windows 2000 / XP / Vista, Mac OS 10.3
Focal length (35mm film equivalent)	35 - 105 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 - ∞ m
Auto focusing (AF) modes	centre weighted auto focus, multi point auto focus, selective auto focus
Closest focusing distance	0.1 m
Macro focusing range (tele)	0.5 - 0.8 m
Macro focusing range (wide)	0.1 - 0.8 m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Flash modes	auto, fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 2 m
Flash range (wide)	0.4 - 3 m
Flash recharging time	4 s
Internal memory	31 MB
Compatible memory cards	mmc, sd, sdhc
Motion JPEG frame rate	20 fps
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Scene modes	Backlight, Night, Night portrait, Portrait, self-portrait, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
Camera playback	movie, single image, slide show
Self-timer delay	2 s
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	17.7 mm
Width	96 mm
Height	56.9 mm
Weight	105 g
