Samsung Techwin User Manual

White balance setup
Auto exposure setup
W B S E T U P
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
W B M O D E
R E D A D J U S T
B L U E A D J U S T
B A C K
E X I T
A E S E T U P
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
B L C
D A Y / N I G H T
A E M O D E
I R I S L E V E L
G A I N L E V E L
S H U T T E R S P D
B R I G H T N E S S
B A C K
E X I T
From the zoom camera setup menu, use the
joystick to highlight WHITE BALANCE SETUP
and key: NEAR
WB MODE (AUTO / MANUAL)
AUTO - the speed dome determines the
optimum white balance settings for a given
scene
MANUAL - the operator can adjust white
balance settings manually
RED ADJUST - in manual mode, the red
colour content can be adjusted
BLUE ADJUST - in manual mode, the blue
colour content can be adjusted
Highlight the item to modify and key: NEAR
Use the joystick to change the setting and key:
NEAR to save or: FAR to cancel.
From the zoom camera setup menu, use the
joystick to highlight AUTO EXPOSURE
SETUP and key: NEAR
BLC (OFF/ ON) - The operator can select
BLC(Back Light Compensation) mode,
selecting will disable this feature.
DAY/NIGHT (AUTO/DAY/NIGHT) - the
operator can choose to fix the camera in to
DAY (colour) or NIGHT (B&W with IR cut filter
mode). In AUTO mode, the camera switches
between DAY and NIGHT depending on the
surrounding light level
AE MODE - in AUTO mode, the speed dome
determines optimum camera exposure
settings for a given scene. In modes other
than AUTO, the operator can adjust specific
exposure characteristics to suit a particular
scene
Highlight the item to modify and key: NEAR
Use the joystick to change the setting and key:
OFF
A U T O
- - -
- - -
O N
A U T O
A U T O
- - -
- - -
- - -
- - -
C A M E R A S E TU P 2
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
P I C F R E E Z E
P I C F L I P
Z O O M S P E E D
F L I C K E R N E S S
W D R
A U T O S L O W S H U T T E R
S T A B A L I Z E R
B A C K
E X I T
O F F
O N
7
O F F
— - -
O F F
— - -
From the dome camera setup menu, use the
joystick to highlight MOTION SETUP and key:
NEAR
PIC FREEZE - when set to ON, there’s no
image flash.
PIC FLIP - when set to ON, the image will be
turned 180 degrees.
ZOOM SPEED - Operator can select zoom
speed.
FLICKERNESS - Should be set to ON when
used in certain lighting conditions (EG
Fluorescent lighting) to prevent picture flicker.
AUTO SLOW SHUTTER - Used to select
shutter speed
Highlight the item to modify and key: NEAR
Use the joystick to change the setting and key:
NEAR to save or: FAR to cancel.
Camera setup2
9
Motion setup
M O T I O N S E TU P
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
A U T O F L I P
J O G S P E E D
J O G D I R E C T I O N
P W R U P A C T I O N
Z O O M P R O P O R T I O N A L
P R E S E T L O C K
< P A R K A C T I O N >
B A C K
E X I T
O N
S L O W
N O R
O N
O N
O F F
From the dome camera setup menu, use the
joystick to highlight MOTION SETUP and key:
NEAR
PWR UP ACTION - when set to ON, the
speed dome will resume its last operation
when power is restored after a power failure
Highlight the item to modify and key: NEAR
Use the joystick to change the setting and key:
NEAR to save or: FAR to cancel.
AUTO FLIP (ON / OFF) - when set to ON, the
dome will flip 180 degrees when the tilt
position reaches 90 degrees.
JOG SPEED - determines the maximum
speed in degrees / second the dome will move
during manual operation
JOG DIRECTION (INVERSE / NORMAL) -
when set to normal, the pan direction is
opposite to the joystick movement.
<ZOOM PROPORTIONAL> - used to select
zoom proportion.
<PARK ACTION> - Configure actions that run
automatically after a defined period of
inactivity
PRESET LOCK - when set to ON, preset
programming directly from the keyboard is
disabled to prevent tampering
