- 10 -
x PTP device is not supported.
x If an over-power warning message is displayed while you are
connecting or using a USB device, the device may not be
recognized or may malfunction.
x If the TV has no input during the time set in Auto Protection Time,
the Screensaver will run.
x The power-saving mode of some external hard disk drives may be
released automatically when your connect them to the TV.
x If you use a USB extension cable, the TV may not recognize the
USB device or may not be able to read the files on the device.
x If a USB device connected to the TV is not recognized, the list of
files on the device is corrupted, or a file in the list is not played,
connect the USB device to a PC, format the device, and check the
connection.
x If a file you deleted from the PC is still found when you run Media
Play, use the “Empty the Recycle Bin” function on the PC to
permanently delete the file.
x Photos only supports sequential jpeg format.
x The scene search and thumbnail functions are not supported in the
Videos.
x If the number of files and folders saved on a USB storage device is
approximately over 4000, the files and folders may not appear and
some folders may not be opened.
x The maximum displayed number of files, including sub folders, in
one folder of USB storage device is 2000.
x The media may not be playing smoothly when using the device
lower than USB 2.0.
Videos
00:04:03 / 00:07:38
1/1
Movie 01.avi
E
Pause
L
Jump
T
Tools
R
Return
1. Press the or button to select Videos, then press the
ENTER
button in the Media Play menu.
2. Press the /// button to select the desired video in the file
list.
3. Press the ENTER
button or
(Play) button.
- The selected file is displayed on the top with its playing time.
- If video time information is unknown, playing time and the
progress bar are not displayed.
- During video playback, you can search using the and
button.
In this mode, you can play movie clips contained in a game, but
you cannot play the game itself.
y Supported Subtitle Formats
- External
Name File extension
MPEG-4 timed text .ttxt
SAMI .smi
SubRip .srt
SubViewer .sub
Micro DVD .sub or .txt
SubStation Alpha .ssa
Advanced SubStation Alpha .ass
- Internal
Name Container Format
Xsub AVI Picture Format
SubStation Alpha MKV Text Format
Advanced SubStation
Alpha
MKV Text Format
SubRip MKV Text Format
MPEG-4 Timed text MP4 Text Format
y Supported Video Formats
File
Extension
Container Video Codec Resolution
Frame
rate(fps)
Bit
rate(Mbps)
Audio
Codec
*.mp4 MP4
DivX
3.11/4.x/5.1/6.0
1920x1080 6~30 30Mbps
MP3 /
ADPCM /
AAC
H264 1920x1080 6~30 30Mbps
AVC 1920x1080 6~30 30Mbps
MJPEG 640x480 6~30 10Mbps
*.avi
*.mkv
AVI,
MKV
DivX
3.11/4.x/5.1/6.0
1920x1080 6~30 30Mbps
MP3 /
AC3 /
LPCM /
ADPCM
/ DTS
Core
MPEG4 SP / ASP 1920x1080 6~30 30Mbps
H264 1920x1080 6~30 30Mbps
MJPEG 640x480 6~30 10Mbps
*.asf
*.wmv
ASF
DivX 3.11 / 4.x
/5.1 / 6.0
1920x1080 6~30 30Mbps
MP3 /
AC3 /
LPCM /
ADPCM
/ WMA /
WMA Pro
MPEG4 SP / ASP 1920x1080 6~30 30Mbps
H.264 1920x1080 6~30 30Mbps
*.ts
*.trp
*.tp
*.m2ts
TS
MPEG2 1920x1080 6~30 30Mbps
AC3 /
AAC /
MP3 /
DD+ /
HE-AAC
H. 264 BP / MP
/ HP
1920x1080 6~30 30Mbps
*.dat
*.mpg
*.mpeg
*.vob
PS
MPEG1 1920x1080 24/25/30 30Mbps
AC3 /
MPEG /
LPCM /
AAC
MPEG2 1920x1080 24/25/30 30Mbps
H. 264 BP / MP
/ HP
1920x1080 6~30 30Mbps
*.3gp 3GPP
MPEG4 SP / ASP 1920x1080 6~30 30Mbps
MP3
H.264 1920x1080 6~30 30Mbps
*.flv
*.swf
flash
formats
H.264 1920x1080 6~30 30Mbps
MP3
Sorenson H.263 1920x1080 6~30 30Mbps
Other Restrictions
y Video content will not play, or not play correctly, if there is an error in the
content or the container.
y Sound or video may not work if the contents have a standard bit rate/
frame rate above the compatible Frame/sec listed in the table above.
y If the Index Table is in error, the Seek (Jump) function is not supported.
y The menu may take longer to appear if the video’s bit rate exceeds
10Mbps.
y Video content can not be played, if there are many contents in one file.
Video Decoder
Supports up to H.264, Level 4.1
H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are not supported.
MPEG4 SP, ASP :
– Below 1280 x 720: 60 frame max
– Above 1280 x 720: 30 frame max
H.263 is not supported.
GMC is not support.
Audio Decoder
Supports up to WMA7, 8, 9 STD, 9 PRO, 10 PRO
WMA 9 PRO and WMA 10 PRO support 5.1 channel. (LBR mode of WMA Pro is
not supported)
WMA Lossless is not supported.
