1.
OPERA
TING RANGE
Maximum
Minimum
115
°
F D
.B.
67
°
F D
.B.
T
emperature
Indoor Air Intake
T
emp.
Outdoor Air Intake
T
emp.
Cooling
95
°
F D
.B.
/ 71
°
F W
.B.
67
°
F D
.B.
/ 57
°
F W
.B.
Maximum
Minimum
115
°
F D
.B.
0
°
F D
.B.
T
emperature
Indoor Air Intake
T
emp.
Outdoor Air Intake
T
emp.
Cooling
Models
:
KS0971 + C0971
KS1271 + C1271
Models
:
KS0971 + CL0971
KS1271 + CL1271
5
4
6
Table of Contents
Table of Contents
3
1 Operating Range
5
2 Specifications
6
Unit Specifications
6
Major Component Specifications
10
Outdoor Unit
12
Other Component Specifications
16
3 Dimensional Data
17
4 Refrigerant Flow Diagram
19
5 Performance Data
20
Temperature Charts
20
Air Throw Distance Charts
24
6 Electrical Data
26
Electrical Characteristics
26
Electric Wiring Diagrams
28
7 Installation Instructions
31
Installation Site Selection
31
Recommended Wire Length and Diameter
33
Remote Control Unit Installation Position
34
How to Test Run the Air Conditioner
35
Remove the Grille to Install the Indoor Unit
36
8 Maintenance
37
Address Setting of the Remote Control Unit
37
Disconnecting and Connecting Positive Connector for Outdoor Unit
38
9 Functions
39
Operation Functions
39
Night Setback
40
Protective Functions
41
10 Troubleshooting
42
Precautions before Performing Inspection or Repair
42
Method of Self-Diagnostics
42
Self-Diagnostics Lamps
43
Indoor Unit Overview
43
Checking the Indoor and Outdoor Units
45
Trouble Diagnosis of Fan Motor
46
Noise Malfunction and Electromagnetic Interference
47
11 Checking Electrical Components
48
Measurement of Insulation Resistance
48
Checking Continuity of Fuse on PCB Ass'y
49
12 Refrigerant R410A: Special Precautions When Servicing Unit
50
Characteristics of New Refrigerant R410A
50
Checklist before Servicing
51
Tools Specifically for R410A
52
Tubing Installation Procedures
52
In Case of Compressor Malfunction
53
In Case Refrigerant Is Leaking
55
Charging Additional Refrigerant
56
Retro-Fitting Existing Systems
56
Appendix Instruction Manual
57
Table of Contents
59
Electrical Requirements
60
Installation Location
60
Safety Instructions
60
Names of Parts
61
Unit Display and Operation Button
62
Remote Control Unit (Display)
63
Remote Control Unit
64
Using the Remote Control Unit
66
Operation with the Remote Control Unit
68
Operation
68
Adjusting the Fan Speed
69
Fan Only
69
Night Setback Mode
70
QUIET Mode
71
HIGH POWER Mode
71
ION Mode
71
Special Remarks
72
Setting the Timer
73
Tips for Energy Saving
75
Using the 1-Hour off Timer
75
Adjusting the Airflow Direction
76
Care and Cleaning
77
Operation Without the Remote Control Unit
77
Operating Range
80
Troubleshooting
80
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Sanyo CL0971 and is the answer not in the manual?
Ask a question
