-35-
Voltages and Waveforms Charts
CRT Board
Q703
E 2.3V
C9V
B 2.1V
Q701
E 2.3V
C 7.6V
B2V
Q705
E 2.3V
C9V
B2V
Q701-B
<B drive>
Q705-C
<G-out>
Q701-C
<B-out>
Q703-C
<R-out>
Q703-B
<R drive>
Q705-B
<G drive>
122Vp-p
4.7Vp-p 128Vp-p
5.1Vp-p
5Vp-p
134Vp-p
Q721
E 0.9V
C0V
B 0V
SM_21-BE4B PWB & WAVEFORM 6/24/08 9:32 AM Page 35
