— 13 —
CHASSIS ELECTRICAL PARTS LIST
CAPACITORS
NOTES:
Read description of the Capacitor as follows:
(Example)
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
less than 10PF
A . .Not specified
B . .±0.1PF C . .±0.25PF
D . .±0.5PF F . .±1PF
G . .±2PF R . .+0.25 - 0PF
S . .+0 - 0.25PF E . .+0 - 1PF
more than 10PF
A . .Not specified
B . .±0.1% C . .±0.25%
D . .±0.5% F . .±1%
G . .±2% H . .±3%
J . .±5% K . .±10%
L . .±15% M . .±20%
N . .±30% P . .+100 - 0%
Q . .+30 - 10% T . .+50 - 10%
U . .+75 - 10% V . .+20 - 10%
W .+100 - 10% X . .+40 - 20%
Y . .+150 - 10% Z . .+80 - 20%
Rated Value: P...Pico Farad U...Micro Farad
Material:
CERAMIC . . . . . .Ceramic
MT-PAPER . . . . .Metalized Paper
POLYESTER . . .Polyester
MT-POLYEST . .Metalized Polyester
POLYPRO . . . . .Polypropylene
MT-POLYPRO . .Metalized Polypropylene
COMPO-FILM . .Composite Film
MT-COMPO . . . .Metalized Composite
STYRENE . . . . . .Styrene
TA-SOLID . . . . .Tantalum Solid
AL-SOLID . . . . . .Aluminum Solid
ELECT . . . . . . . .Electrolytic
NP-ELECT . . . . .Non-Polarized Electrolytic
OS-SOLID . . . . .Aluminum Solid with Organic
Semiconductive Electrolytic
C001 404 084 3801 ELECT 1U M 50V
C002 404 084 3801 ELECT 1U M 50V
C005 404 087 1200 ELECT 0.1U M 50V
C007 404 089 2700 ELECT 100U M 25V
C008 403 224 6009 CERAMIC 4700P K 50V
C009 403 224 6009 CERAMIC 4700P K 50V
C010 404 084 3306 ELECT 470U M 16V
C011 404 084 3306 ELECT 470U M 16V
C015 404 087 2306 ELECT 220U M 25V
C017 403 357 9601 CERAMIC 0.1U Z 50V
C101 404 084 2200 ELECT 100U M 6.3V
C103 403 224 6108 CERAMIC 0.01U K 50V
C106 404 084 4105 ELECT 3.3U M 50V
C128 404 084 2705 ELECT 10U M 16V
C130 403 224 5705 CERAMIC 1000P K 50V
C131 404 084 3801 ELECT 1U M 50V
C133 403 224 6108 CERAMIC 0.01U K 50V
C134 403 235 5404 CERAMIC 1500P K 50V
C137 403 364 7508 CERAMIC 10P J 50V
C142 403 343 4603 CERAMIC 0.022U K 50V
C143 403 224 6108 CERAMIC 0.01U K 50V
C146 403 224 6108 CERAMIC 0.01U K 50V
C147 404 084 2200 ELECT 100U M 6.3V
C151 404 084 3702 ELECT 0.47U M 50V
C153 404 084 3702 ELECT 0.47U M 50V
C161 403 357 9601 CERAMIC 0.1U Z 50V
C211 403 069 8305 CERAMIC 0.01U Z 50V
C212 404 084 4006 ELECT 2.2U M 50V
C221 404 084 6901 NP-ELECT 1U M 50V
C247 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
C252 403 057 3107 POLYESTER 0.1U K 50V
403 311 8909 POLYESTER 0.1U K 50V
404 084 5102 POLYESTER 0.1U K 63V
CAUTION: To Protect against electrical shock and for continued product safety, refer to SAFETY PRECAUTIONS,
X-RADIATION PRECAUTIONS, HIGH VOLTAGE HOLD-DOWN TEST, and PRODUCT SAFETY NOTICE on Page 2.
Notes: Parts having Location Number are located on the following boards.
Numbers 300, 1000, 3400 Series . . . . . . . . . . . . . . . . .On the AV Board and Main Board
Numbers 400 Series . . . . . . . . . . . . . . . . . . . . . . . . . . .On the PCC Board and Main Board
Numbers 700 Series . . . . . . . . . . . . . . . . . . . . . . . . . . .On the Picture Tube Socket Board.
Numbers 900 Series . . . . . . . . . . . . . . . . . . . . . . . . . . .Out of Board.
Numbers 1700 Series . . . . . . . . . . . . . . . . . . . . . . . . . .On the Picture Tube Socket Board and Main Board
All Other Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . .On the Main Board
PRODUCT SAFETY NOTICE
PRODUCT SAFETY SHOULD BE CONSIDERED WHEN A REPLACEMENT IS MADE IN ANY AREA OF A RECEIVER.
COMPONENTS INDICATED BY A STAR (★) IN THIS PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE
COMPONENTS IN WHICH SAFETY CAN BE OF SPECIAL SIGNIFICANCE. IT IS PARTICULARLY RECOMMENDED
THAT ONLY PARTS DESIGNATED ON THE FOLLOWING PARTS LIST BE USED FOR COMPONENT REPLACEMENT
DESIGNATED BY A STAR. NO DEVIATIONS FROM RESISTANCE,WATTAGE,AND VOLTAGE RATINGS MAY BE MADE
FOR REPLACEMENT ITEMS DESIGNATED BY A STAR.
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
Note: Schematic part location numbers may not always match with the part descriptions.
The part descriptions are correct and should be used.
