OPERATION
CONTROLS AND FUNCTION KEYS
1. LIQUID CRYSTAL DISPLAY PANEL
In radio mode, the frequency, preset number, etc. will be shown on the display. In tape mode,
the direction indicator appears on the display.
2. CASSETTE COMPARTMENT
Insert the cassette with the exposed tape facing to the right. The unit will switch to TAPE
mode automatically.
3. OFF/VOLUME
Rotate the knob to switch the power on or off and to adjust the volume.
BALANCE (push)
Push and rotate the knob to adjust the sound balance between the left and right speakers.
4. FADER
Rotate the knob to adjust the sound balance between the front and rear speakers.
5. TONE
Rotate the knob to adjust the the high frequency sound level.
6. TUNE/SEEK/ATP (AUTO TUNING PRESET) CONTROL
This button performs two functions: Auto Tuning Preset Scan and Auto Tuning Preset
Memory. This function allows you to locate and store up to six stations in the selected band
automatically. Select the desired band, then rotate the knob counterclockwise to select a
station on a lower frequency or clockwise to select a station on a higher frequency. Hold the
knob in either position for more than 0.5 seconds to begin automatic scanning. The tuner
will locate and stop at the next receivable station.
Auto Memory Scan Function
Use this function to check the stations stored in memory. Press the ATP button to select the
preset stations for five seconds each, beginning with the current station, Either press the ATP
button again or press one of the preset buttons (1-6) to stop scanning. During the preset
scan operation, the preset number flashes on the display.
2
3 8
1
7 2 10 6
124 11 5139
