Cooling unit parts
<MDF-U53V/U53VC>
Specifications
Item
H side L side
Compressor 220V, 60Hz 220V, 50Hz 230/240V, 50Hz
Code 7FB-0-M101-001-06 7FB-0-M101-001-04 7FB-0-M101-001-05
Type KS370J1NS-7A KS370J1NS-4A KS370J1NS-4A1
Refrigerant oil
Ze-NIUS32SA
Charged q’ty: 850cc
Ze-NIUS32SA
Charged q’ty: 850cc
Cooling system
Forced air cooling（partially）
Oil cooler
Forced air cooling（partially）
Oil cooler
Condenser
Type Fin and tube Cascade condenser
Condenser 12 columns x 4 lines P6.35mm
Fin 88pcs.
Coil pipeφ6.35mm
Pre-condenser W 250mm ʊ
Frame pipe
φ4.76mm
ʊ
Evaporator
Type
Cascade condenser
Shell and tubeφ80mm
Tube on sheet
φ9.52mm
Capillary tube Ex. capillary
Resistance
PSI・kg/cm
2
94 PSI/G 98 PSI/G 34 PSI/G
 Length 1800mm 1200mm 500mm
Outer diameter
φ2.0mm φ2.0mm φ2.4mm
Inner diameter
φ1.0mm (φ0.9mm) φ1.2mm
Refrigerant R-407D Charged q’ty: 564g R-508 Charged q’ty: 260g
Oil additive
n-Pentane
Charged-q’ty: 60cc (36g)
n-Pentane
Charged q’ty: 58cc (36.8g)
Dryer 4A-XH-9 Charged q’ty: 18g 4A-XH-6 Charged q’ty: 58g
Condensing fan
φ230 mm、4 blades
Material: ABS
Condensing fan
motor Type SE4-E11L3P (high stage side)
Oil separator
ʊ
SPK-0S02S2
(810-4-2008)
<Compressor terminals layout>

C
S
R
