Sanyo MDF-U73VC User Manual

11
Specifications of sensor
The following shows the temperature in thermal sensor (502AT-1) and its resistance value.
Temp.
(C)
Resistance
Value (kΩ)
Temp.
(C)
Resistance
Value (kΩ)
Temp.
(C)
Resistance
Value (kΩ)
Temp.
(C)
Resistance
Value (kΩ)
−50
154.5
−36
71.80
−22
35.65 0 13.29
−49
145.9
−35
68.15
−21
33.99 5 10.80
−48
137.8
−34
64.71
−20
32.43 10 8.84
−47
130.2
−33
61.48
−19
30.92 15 7.20
−46
123.1
−32
58.43
−18
29.50 20 6.01
−45
116.5
−31
55.55
−17
28.14 25 5.00
−44
110.2
−30
52.84
−16
26.87 30 4.17
−43
104.4
−29
50.23
−15
25.65 35 3.50
−42
98.87
−28
47.77
−14
24.51 40 2.96
−41
93.70
−27
45.45
−13
23.42 45 2.51
−40
88.85
−26
43.26
−12
22.39 50 2.13
−39
84.18
−25
41.19
−11
21.41 55 1.82
−38
79.80
−24
39.24
−10
20.48 60 1.56
−37
75.67
−23
37.39
−5
16.43 65 1.35


The following shows the temperature in thermal sensor (PT1000ȍ) and its resistance value.
Temp.
(C)
Resistance
Value (Ω)
Temp.
(C)
Resistance
Value (Ω)
Temp.
(C)
Resistance
Value (Ω)
−140
450.83
−70
729.99 0 1000.0
−130
491.47
−60
769.02 10 1038.0
−120
531.83
−50
807.87 20 1076.0
−110
571.92
−40
846.58 30 1113.8
−100
611.76
−30
885.13 40 1151.4
−90
651.38
−20
923.55 50 1189.0
−80
690.78
−10
961.84 60 1226.4
