Sanyo MDF-U73VC User Manual

10
Compressor (H),(L)
Type KS370J1NS-7
A
KS370J1NS-4
A
KS370J1NS-4AI
Code 7FB-0-M101-001-06 7FB-0-M101-001-04 7FB-0-M101-001-05
Rated voltage (50/60Hz) 220V, 60Hz 220/230V, 50Hz 230/240V, 50Hz
Winding resistance C-S(Aux) 1.64㱅 2.53㱅 2.53㱅
C-R(Main) 3.35㱅 4.8㱅 4.8㱅
Starting relay(H), (L)
Type AMVL-300
A
AMVL-300
A
AMVL-300
A
Pick up voltage 215~247VAC(60Hz) 185~217VAC(50Hz) 185~217VAC(50Hz)
Drop out voltage 69~132VAC(60Hz) 60~120VAC(50Hz) 60~120VAC(50Hz)
Parts code 626 100 1503 626 100 1503 626 100 1503
Overload relay (H), (L)
Type MRA999549201 MRA999539201 MRA999539201
Action to the temp. (no current) ON:69±11㷄 OFF:135±5㷄 ON:69±11㷄 OFF:135±5㷄 ON:69±11㷄 OFF:135±5㷄
Action to the current (AT25℃) 29.5A 22.5A 22.5A
Operation time 6~16sec. 6~16sec. 6~16sec.
Parts code 624 226 3173 624 226 3166 624 226 3166
Starting capacitor(H),(L) Rating 250VAC, 10MF 250VAC, 10MF 250VAC, 10MF
Running capacitor (H),(L
)
Rating 400VAC, 25MF 400VAC, 25MF 400VAC, 25MF
Condensing fan moto
r
Type SE4-E11L5P SE4-E11L5P SE4-E11L5P
Rating 220-240VAC 220-240VAC 220-240VAC
Parts code 624 224 0167 624 224 0167 624 224 0167
Cap.tube heater
Rating 230V, 12W 230V, 12W 230V, 12W
Parts code 624 200 0280 624 200 0280 624 200 0280
H Comp. rela
y
Type G4F-11123T G4F-11123T G4F-11123T
Contact capacit
y
20A, 250VAC 20A, 250VAC 20A, 250VAC
Coil 12VDC 12VDC 12VDC
Parts code 624 173 2397 624 173 2397 624 173 2397
Heater rela
y
Type G2R-1A-T G2R-1A-T G2R-1A-T
Contact capacit
y
10A, 250VAC 10A, 250VAC 10A, 250VAC
Coil 12VDC 12VDC 12VDC
Parts code 624 188 9299 624 188 9299 624 188 9299
Temp. control rela
y
Type G4F-11123T G4F-11123T G4F-11123T
Contact capacit
y
20A, 250VAC 20A, 250VAC 20A, 250VAC
Coil 12VDC 12VDC 12VDC
Parts code 624 173 2397 624 173 2397 624 173 2397
Switching power suppl
y
Type LDA10F-12 LDA10F-12 LDA10F-12
Rated output 12VDC, 0.9
A
12VDC, 0.9
A
12VDC, 0.9
A
Parts code 624 226 2053 624 226 2053 624 226 2053
Temperature sensor
Type SS-12-T SS-12-T SS-12-T
Rating 1000㱅 1000㱅 1000㱅
AT senso
r
Type 502AT 502AT 502AT
Rating 5K㱅, 25㷄 5K㱅, 25㷄 5K㱅, 25㷄
Filter sensor
Type 502AT 502AT 502AT
Rating 5K㱅, 25㷄 5K㱅, 25㷄 5K㱅, 25㷄
Cascade senso
r
Type 502AT 502AT 502AT
Rating 5K㱅, 25㷄 5K㱅, 25㷄 5K㱅, 25㷄
Door switch
Type SDKNA20700 SDKNA20700 SDKNA20700
Rating 5V, 5MA 5V, 5MA 5V, 5MA
Noise filte
r
Type ZAC2220-11 ZAC2220-11 ZAC2220-11
Rating 250VAC, 20
A
250VAC, 20
A
250VAC, 20
A
Power cord
Type GTVD-2,3 GTVD-2,3 GTVD-2,3
Battery switch
Type SLE6A2-5 SLE6A2-5 SLE6A2-5
Rating 250VAC, 4
A
250VAC, 4
A
250VAC, 4
A
Type 5HR-AAC 5HR-AAC 5HR-AAC
Rating 6V, 1100mAH 6V, 1100mAH 6V, 1100mAH
Parts code 624 209 9284 624 209 9284 624 209 9284
Handle heate
r
Rating 9VAC, 0.83W 9VAC, 0.83W 9VAC, 0.83W
Transformer
Type S41-RN97P
V
S41-RN97P
V
S41-RN97P
V
Primar
y
115V 115V 115V
Secondar
y
230V 230V 230V
Parts code 624 226 7645 624 226 7645 624 226 7645
Breaker switch
Type BAM215131 BAM215131 BAM215131
Rating 250V, 15A 250V, 15A 250V, 15A
Boost rela
y
Type G7L-1A-TUB
(MDF-U53VC only)
Rating 30A, 220V, DC24V
Power rela
y
Type DS1E-M-DC12V
(MDF-U53VC only)
Rating 12V, 0.4A, 125V
Breaker switch
Type IR11A2E201
R
(MDF-U53VC only)
Rating 250VAC, 20
A
Power transformer
Type ATR-HJ61TC-1
(MDF-U53VC only)
Rating 200, 225, 240V
Power transformer
Type ATR-D35003
(MDF-U53VC only)
Rating P;208V, S;230V
* For the compressor specified for China;
Type: KS370J1NS-4A (CCC authorized)
230/240VAC, 50Hz
220VAC, 50Hz
Battery
220VAC, 60Hz
MDF-U53V/U53VC
Electrical Parts
