– 9 –
CAUTION: To Protect against electrical shock and for continued product safety, refer to SAFETY PRECAUTIONS
and PRODUCT SAFETY NOTICE on Page 2
PRODUCT SAFETY NOTICE
PRODUCT SAFETY SHOULD BE CONSIDERED WHEN A REPLACEMENT IS MADE IN ANY AREA OF A RECEIVER.
COMPONENTS INDICATED BY A IN THIS PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE
COMPONENTS IN WHICH SAFETY CAN BE OF SPECIAL SIGNIFICANCE. IT IS PARTICULARLY RECOMMENDED
THAT ONLY PARTS DESIGNATED ON THE FOLLOWING PARTS LIST BE USED FOR COMPONENT REPLACE-
MENT DESIGNATED BY A . NO DEVIATIONS FROM RESISTANCE, WATTAGE, AND VOLTAGE RATINGS MAY
BE MADE FOR REPLACEMENT ITEMS DESIGNATED BY A .
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
Note: Schematic part location numbers may not always match with the part descriptions.
The part descriptions are correct and should be used.
CAPACITORS
RESISTORS
CHASSIS ELECTRICAL PARTS LIST
NOTES:
Read Description of the Capacitor as follows:
(Example)
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A : Not specified
D : ±0.5pF
G : ±2pF
R : ±0.25-0pF
B : ±0.1pF
E : +0-1pF
H : +0.1-0pF
S: ±0.25-0pF
C : ±0.25pF
F : ±1pF
L : +0-0.1pF
More than 10pF
A : Not specified
D : ±0.5%
H : ±3%
L : ±15%
P : +100-0%
U : +75-10%
X : +40-20%
B : ±0.1%
F : ±1%
J : ±5%
M : ±20%
Q : +30-10%
V : +20-10%
Y : +150-10%
C : ±0.25%
G : ±2%
K : ±10%
N : ±30%
T : +50-10%
W : +100-10%
Z : +80-20%
Rated value: P=pico tarad, U=micro tarad
Material:
CERAMIC . . . . . . .
MT-PAPER. . . . . . .
POLYESTER . . . . .
MT-POLYEST . . . .
POLYPRO . . . . . . .
MT-POLYPRO . . . .
COMPO FILM . . . .
MT-COMPO. . . . . .
STYRENE . . . . . . .
TA-SOLID . . . . . . .
AL-SOLID . . . . . . .
ELECT . . . . . . . . . .
NP-ELECT . . . . . . .
OS-SOLID . . . . . . .
Ceramic
Metallized Paper
Polyester
Metallized Polyester
Polypropylene
Metallized Polypropylene
Composite Film
Metallized Composite
Styrene
Tantalum Solid
Aluminum Solid
Electrolytic
Non-polarised Electrolytic
Alluminum Solid with Organic
Semiconductive Electrolytic
NOTES:
Read Description of the Resistor as follows:
(Example)
CARBON 4.7K J A 1/4W
Rated Wattage
A...0.05%
D...0.5%
J...5%
P...+5-15%
B...0.1%
F...1%
K...10%
C...25%
G...2%
M...20%
Rated value, ohms:
K...1,000 M...1,000,000
Material:
CARBON . . . . . . . .
MT-FILM . . . . . . . .
OXIDE-MT. . . . . . .
SOLID . . . . . . . . . .
MT-GLAZE . . . . . .
WIRE WOUND . . .
CERAMIC RES . . .
FUSIBLE RES . . . .
Carbon
Metal Film
Oxide Metal Film
Composition
Metal Glaze
Wire wound
Ceramic
Fusible
Performance Symbols:
A...General B..Non-flammable
Z...Low noise
Other...Temperature coefficient
Tolerance Symbols:
To Next Page
