– 4 –
Table 1. ON-SCREEN SERVICE MENU
When IC5750 (Flash Memory) is replaced, check the bus data to confirm they are the same as below. See page 3 for
On-Screen Service Menu access and adjustments.
PROGRAM CODES
The microprocessor used in this model is a multi-purpose type and is used in several different models. To ensure
proper operation and the correct features for your particular model, the program codes must be correct.
Note 1. Option Data 1 (Index 02) should be hexadecimal 00.
See Index 02 above. If this program code is wrong the TV will not operate properly.
Note 2. Option Data 2 (Index 03) should be hexadecimal 33.
See Index 03 above. If this program code is wrong the TV will not operate properly.
NOTES: Option 2 Data (Display Panel)
Option 1 and Option 2 data is initial and can be set according to adjusment information.
Index ParameterName Value Min Max
02 OP1 00h 0 255
03 OP2 33h 0 255
ON-SCREEN SERVICE MENU
