Sanyo P46841-03 User Manual

– 12 –
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
DIODES
D002 B0ACCK000019 DIODE 1SS355
B0ACDJ000007 DIODE 1SS352-(TPH3)
B0ACDJ000017 DIODE 1SS352(TH3 F T)
DDDA2J10100LG DIODE DA2J10100L
D003 B0ACCK000019 DIODE 1SS355
B0ACDJ000007 DIODE 1SS352-(TPH3)
B0ACDJ000017 DIODE 1SS352(TH3 F T)
DDDA2J10100LG DIODE DA2J10100L
D007 B0BC6R100010 ZD UDZS-TE-176.2B
B0BC6R2A0384 ZENER DIODE MM3Z6V2B
DZDZ2J062M0LG ZD DIODE DZ2J062M0L
D008 B0BC6R100010 ZD UDZS-TE-176.2B
B0BC6R2A0384 ZENER DIODE MM3Z6V2B
DZDZ2J062M0LG ZD DIODE DZ2J062M0L
D6700 B0ACCK000019 DIODE 1SS355
B0ACDJ000007 DIODE 1SS352-(TPH3)
B0ACDJ000017 DIODE 1SS352(TH3 F T)
DDDA2J10100LG DIODE DA2J10100L
INTEGRATED CIRCUITS
IC001 C1AB00003628 IC STA333W13TR
IC5500 C1AB00003956 IC ZR39748HGCG
IC5700 C3ABSY000102 IC H5PS5162GFR-S6C
IC5750 QXXAAJQ1300— IC S25FL064P0XMFI0 N8LJ
IC5900 C0EBY0001079 IC XC6118N28AMR-G
IC6250 C0ABBB000350 IC BA4558RF-E2
C0ABBB000450 IC NJM4558M-TE2
IC6500 C0JBAA000345 “IC TC7SET08FU(T5L,JF)”
C0JBAA000502 “IC TC7SET08FU(5L,JF,T”
C0JBAA000505 IC 74AHCT1G08GW
IC6530 C0JBAA000345 “IC TC7SET08FU(T5L,JF)”
C0JBAA000502 “IC TC7SET08FU(5L,JF,T”
C0JBAA000505 IC 74AHCT1G08GW
IC6560 C0JBAA000345 “IC TC7SET08FU(T5L,JF)”
C0JBAA000502 “IC TC7SET08FU(5L,JF,T”
C0JBAA000505 IC 74AHCT1G08GW
IC6600 C0DBZYY00485 IC NCP380HSN05AAT1G
IC6700 C0CBAYG00009 IC LM1117S-ADJ
IC6720 C0DBAYY01122 IC BD9328EFJ-E2
IC6750 C0DBGYY02242 IC AP2128K-ADJTRG1
COILS
L001 G1C220MA0445 “INDUCTOR ,22UH”
L002 G1C220MA0445 “INDUCTOR ,22UH”
L003 G1C220MA0445 “INDUCTOR ,22UH”
L009 J0JCC0000371 “INDUCTOR , 120 OHM”
L011 J0JYC0000381 “INDUCTOR , 220 OHM”
L012 J0JYC0000381 “INDUCTOR , 220 OHM”
L013 G1C220MA0445 “INDUCTOR ,22UH”
L017 J0JCC0000371 “INDUCTOR , 120 OHM”
L5500 J0JCC0000371 “INDUCTOR , 120 OHM”
L5501 J0JCC0000371 “INDUCTOR , 120 OHM”
L5502 J0JCC0000371 “INDUCTOR , 120 OHM”
L5503 J0JYC0000381 “INDUCTOR , 220 OHM”
L5504 J0JYC0000381 “INDUCTOR , 220 OHM”
L5505 J0JCC0000371 “INDUCTOR , 120 OHM”
L5506 J0JCC0000371 “INDUCTOR , 120 OHM”
L5507 J0JCC0000371 “INDUCTOR , 120 OHM”
L5508 J0JCC0000371 “INDUCTOR , 120 OHM”
L5509 J0JCC0000371 “INDUCTOR , 120 OHM”
L5510 J0JCC0000371 “INDUCTOR , 120 OHM”
L5511 J0JCC0000371 “INDUCTOR , 120 OHM”
L5512 D0GB750JA041 MT-GLAZE 75 JA 1/10W
D0GB750JA072 MT-GLAZE 75 JA 1/10W
D0GB750JA089 MT-GLAZE 75 JA 1/10W
L5513 J0JCC0000371 “INDUCTOR , 120 OHM”
L5514 J0JCC0000371 “INDUCTOR , 120 OHM”
L5515 J0JCC0000371 “INDUCTOR , 120 OHM”
L5516 G1CR22JA0135 “INDUCTOR ,0.22UH”
L6313 J0JAD0000028 “IMPEDANCE,200 OHM M”
L6314 J0JAD0000028 “IMPEDANCE,200 OHM M”
L6315 J0JAD0000028 “IMPEDANCE,200 OHM M”
L6316 J0JAD0000028 “IMPEDANCE,200 OHM M”
L6317 J0JAD0000028 “IMPEDANCE,200 OHM M”
L6318 J0JAD0000028 “IMPEDANCE,200 OHM M”
L6720 G1C220MA0445 “INDUCTOR ,22UH”
L6721 D0GDR00JA072 MT-GLAZE 0.000 ZA 1/10W
D0GDR00Z0002 MT-GLAZE 0.000 ZA 1/10W
D0GDR00JA072 MT-GLAZE 0.000 ZA 1/10W
D0GDR00Z0002 MT-GLAZE 0.000 ZA 1/10W
TRANSISTORS
Q6250 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6251 B1ADCF000004 TR 2SA1037AK-S-T146
B1ADCF000194 TR ISA1235AC1F
B1ADCF000195 TR 2SA1037AK-T146-R
B1ADCF000201 TR ISA1235AC1E
B1ADDF000004 TR 2SA1235A1F
Q6252 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6329 B1CHPD000006 TR CPH3338-T-TL-E
B1DHDD000041 TR AO3407A
Q6331 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6700 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6701 B1CHPD000006 TR CPH3338-T-TL-E
B1DHDD000041 TR AO3407A
Q6720 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
B1ABDF000024 TR 2SC3928A1S
Q6721 B1ABCE000028 TR MMBTSC3928R
B1ABDF000013 TR 2SC3928A1R
