-61-
Control Port Functions
Scaler I/O Port Functions (PW190)
PIN
NO.
PORT
NO.
PORT NAME FUNCTION
SIGNAL
NAME
DESCRIPTION I/O
11 A11 PORTC5 ON_3.3V 3.3V Power Drive, Power On: H O
110 B11 PORTC6 ON_5V 5VA Drive On/Off, On: H O
111 B12 PORTC1 SCS_PW 3-Wired Serial Control O
124 B25 TXD_PW TXD_PW Serial Control RXD O
201 C11 PORTC7 ON_150V 15V Power Driver,Pow on:H O
202 C12 PORTC2 SDATA_PW 3-Wired Serial Control Data O
205 C15 PORTI7 PW_NMCLR LAN control I
208 C18 PORTH5 2-Wire Serial Data 2 SDA2 IIC Bus Switch IC DAC, SoundIC[5V_SW] O
211 C21 PORTH1 2-Wire Serial Clock 1 SCL1 O
212 C22 PORTH7 2-Wire Serial Data 0 SDA0 IIC Bus Temp Sensor [S3.3V] O
28 C26 ADC1 KEY1 Input/Select/Keystone I
278 D5 PORTD5 ID PWR SW lamp ID power 5V ON/OFF I
284 D11 PWM1 BLAST_AC Ballast CTL O
285 D12 PORTC3 LAMP_DET LampErrorDet Low=Error I
290 D17 PORTH4 2-Wire Serial Clock 2 SCL2 IIC Bus Control Clock O
293 D20 PORTH6 2-Wire Serial Clock 0 SCL0 IIC Bus Control Clock O
294 D21 PORTH3 2-Wire Serial Data 1 SDA1 IIC Bus Control Data O
296 D23 PORTI6 PW_UPDATE LAN control O
215 D24 ADC0 ADC0 P_FAIL Power Failure Signal Input, Failure:L I
126 D25 ADC2 ADC2 KEY-2 Key Control Input I
29 D26 ADC6 ADC6 LAMP Option Lamp Option I
362 E14 PORTC4 IRM_RST L3E07111 reset O
368 E20 PORTH0 RXD_PW Serial Control RXD I
370 E22 ADC5 ADC5 P_FAIL_LAN LAN error detect I
30 E26 DAC1 DAC1 FAN CON_A FAN CON_A O
298 F23 ADC4 ADC4 BRAND Option Option Switch BRAND I
128 F25 DAC2 DAC2 FAN CON_B FAN CON_B O
373 H22 DAC0 DAC0 FAN_CON_C FAN_CON_C O
92 K1 PORTB3 DG[1] O
185 K2 PORTB1 DB[1] O
347 K4 PORTD5 LAN-RESET UART control I
91 L1 PORTB5 DR[1] O
184 L2 PORTB6 PW_LAMP_ID_A lamp ID O
346 L4 PORTB4 DR[0] O
183 M2 PORTA1 POWER_ON_LAN POWER_ON_LAN O
268 M3 PORTB0 DB[0] O
345 M4 PORTB2 DG[0] O
89 N1 PORTA3 LAMP_DC_ON Power Control, Power On: H O
267 N3 PORTA6 S_SW S_Video DET, Low=Connect, High=NC I
344 N4 PORTA7
MUTE
High=Mute_ON O
413 N5 PORTA4
MONIT_OUT Low=in, High=Monit OUT
O
474 N6 PORTA2 SW_PNL_REF 15.5V for PANEL REF on/off O
329 AC9 PORTD2 A[22] A[22] O
242 AD17 EXTINT0 XINT PW_LAN_INT UART INTERRUPT O
160 AE12 PORTD0 A[20] A[20] O
72 AF12 PORTD1 A[21] A[21] O
