38
7-2. Remote Control Unit Installation
Position
The remote control unit can be operated from either a
non-fixed position or a wall-mounted position.
To ensure that the air conditioner operates correctly, do
not install the remote control unit in the following places:
●
In direct sunlight
●
Behind a curtain or other place where it is covered
●
More than 8 m away from the air conditioner
●
In the path of the air conditioner's airstream
●
Where it may become extremely hot or cold
●
Where it may be subject to electrical or magnetic
interference
6-1. When attaching to wall (Fig.6a)
1) Confirm the indoor unit beeps when the ON/OFF
button is pressed at the wall location where the
remote control unit is to be attached, then attach
the holder to the wall.
2) When taking out the remote control unit, pull it
from the holder.
When using the remote control unit
• Point the transmission portion of the remote
control unit at the receiver area of the indoor unit
when operating the remote control unit, and
during operation of the air conditioner.
• Do not place objects which may block the
transmitted signals between the receiver and the
remote control unit.
When mounting the remote control unit to
prevent theft (Fig.6b)
1) Attach the holder to the wall with one of the
screws (using only the hole in the top of the
holder).
2) Remove the cover of the remote control unit and
take out the batteries. Next, place the remote
control unit in the holder.
3) Fasten both the remote control unit and holder to
the wall with the remaining screw (using the hole
in the bottom of the holder).
4) Install the batteries in the remote control unit and
close the cover.
