OI-378-05EG
5
Names of Parts
Air Intake Air from the room is drawn into these sections and passes through air
filters which remove dust.
Air Outlet Air is blown out of the air conditioner through the air outlet.
Remote Control Unit The wireless remote control unit controls power on/off, operation mode
selection, temperature, fan speed, timer setting, and air sweeping.
Refrigerant Tubes The indoor and outdoor units are connected by copper tubes through
which refrigerant gas flows.
Drain Hose Moisture in the room condenses and drains off through this hose.
Outdoor (Condensing) Unit The outdoor unit contains the compressor, fan motor, heat exchanger
coil, and other electrical components.
Air outlet
Drain hose
Refrigerant
tubes
Air outlet
Air intakes
INDOOR UNIT
OUTDOOR UNIT
Remote
control
unit
This illustration is based on the external appearance of a standard
model. Consequently, the shape may differ from that of the air
conditioner you have selected.
This air conditioner consists of an indoor unit and an outdoor unit.You
can control the air conditioner with the remote control unit.
NOTE
SAP-K121GJA-oi 3/4/00 16:49pm Page 5
